Consumer Electronics Drop Impact Test Machine OEM / ODM Acceptable
Negotiable
/ Piece
1 Piece(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
LABTONE Vibration Shaker Table Systems With MIL-STD / AS 9000 Standard
-
DT030 Lab Drop Tester , Quick Release Drop Tester Easy Install
-
MIL-STD-810 Vibration Testing Machine Frequency Range 2-2500 Hz
-
Professional Vibration Testing Machine For Sinusoidal Vibration Test 250 Cm/S Max Velocity
-
High Force 50kN Vibration Testing Machine With ISO 5344 Low Power Consumption
-
Digital Drop Weight Test Machine , Drop Test Equipment 4500kg
Product Details
| Brand Name | LABTONE | Place of Origin | China | |
| Model Number | DT030 |
Product Description
Certification:CE ISO
Consumer Electronics Package Carton Drop Height Packaging Drop Test Machine
Product Description
For the massive packing goods and the mass is large, the vertical drop height is relatively low in the transportation and handling. So the Standard Free DropTest Equipment for Heavy Packaged Cargo is relatively low. This drop tester is mainly used for larger package drop test. Zero height drop tester use a quickly moves down E fork mounting as bracket. The specimen place balance as the test requirment(plane, edge,angle). When doing the test, the bracket do high-speed downward movement before the specimen, acceleration >3g, it need guarantee the bracket separate with the specimen and realize free fall. The standard drop height range is 2.54cm-120cm.
.
Consumer Electronics Package Carton Drop Height Packaging Drop Test Machine Specification
| Model | DT015 | DT020 | DT030 |
| Drop height(mm) | 0----1200 | 0----1200 | 0---1200 |
| Specimen weight(KG) | 150 | 200 | 300 |
| Specimen dimension(mm) | 1000*1000*1000 | 1200*1200*1200 | 1200*1200*1200 |
| Drop type | Free drop | ||
| Machine dimension(mm) | 1900*1700*2800 | 2100*1700*2800 | 2100*1700*2800 |
| Machine Weight(kg) | 2500 | 3200 | 4500 |
| Power supply | 3 phase AC380V 50HZ | ||
| Standards | ISO2248-72(E) GB/T4857.5 JISZ0202-87 IEC68-2-27 | ||
Detail Pictures
Functions and Features
1 With upper and lower displacement limit, safety and reliability;
?
2 Lifting height can be adjusted arbitrarily to meet the needs of different users;
?
3 Zero freely-drop test stand adopts the double-rail guiding device for stable and reliable lifting operation;
?
4 The freely-drop test stand can achieve the clamping fall tests for surface, edge and corners of ? ? specimen at different direction;
?
5 The machine is only needed to be placed on the flat marble or concrete ground for installation, without ? special foundation.
Labtone Service
| Pre-sales service: |
| Technical Advisory: Testing method, laboratory planning and advice |
| Equipment Selection: Type-selecting scheme,FAQ |
| Product testing scheme |
| ? |
| Selling service: |
| Customer Communication,progress communication |
| Before installation, we will provide guidance of preparation , equipment debugging, equipment commissioning |
| Cooperate with measuring if need the third party verification |
| ? |
| After-sale service: |
| Quality assurance period for one year,lifelong maintenance. |
| Technical guidance |
| Feedback within 2 hours after get the call. |
| Accept OEM,Design service,Buyer lable |
