GD-580T Injection Molding Machine/Injectin Machine/Palstic Machine

GD series of auto plastic injection machine are with Injection weight 45-3590g and Clamping Force 50-680tons. LCD computer control, Famous-brand of hydraulic/electrical/sealing system. They areavailable to injection molding of various thermoplastics such as PC, PP, PE, Nylon, A.B.S.PET.PVC etc. And can produce all kinds of medium-or small-size plastic articles and daily-use commodities

Competitive Advantages of the product

* Top class quality

* Excellent human resources

* Prompt delivery schedules

* Value for money

* Transparent trade practices

1.automaticdouble proportional valveposition transducer duplex pump

2.If hydraulic core pulling device is required,extra charge is neededEach will take you1500 more

3.Freight is not included

4.Variable displacement pump takes 15000 more for ecah setServo-energe saving series 50T-150T each set will cost 25000 more150T-350T each costs 45000 more

5.It can be customized based on your requirements.May be extra charge will be needed in that case

(A).Feature of 580T injection molding machine:

Space between tie brs: 840*820mm

Maximum mould thickness:850mm

Minimum mould thickness:350mm

It can be customized based on your requirements.

(B).The main parameters of this injection moulding machine:

Plastic shot volume 2547,2780,3245,3460g

Screw diameter 90,95,100,105mm

Plastic pressure radio 142,128,115,103Mpa

Screw speed 0-130rpm

Weight 25000kg

Die edge 5800kN

Die stroke to open 850mm

Main motor power 55kw

Overall dimension 9300*2300*3100mm
