GD-400T Injection Molding Machine/Injection Machine/Molding Machine

GD series of auto plastic injection machine are with Injection weight 45-3590g and Clamping Force 50-680tons. LCD computer control, Famous-brand of hydraulic/electrical/sealing system. They areavailable to injection molding of various thermoplastics such as PC, PP, PE, Nylon, A.B.S.PET.PVC etc. And can produce all kinds of medium-or small-size plastic articles and daily-use commodities

Competitive Advantages of the product

* Top class quality

* Excellent human resources

* Prompt delivery schedules

* Value for money

* Transparent trade practices

1.automaticdouble proportional valveposition transducer duplex pump

2.If hydraulic core pulling device is required,extra charge is neededEach will take you1500 more

3.Freight is not included

4.Variable displacement pump takes 15000 more for ecah setServo-energe saving series 50T-150T each set will cost 25000 more150T-350T each costs 45000 more

5.It can be customized based on your requirements.May be extra charge will be needed in that case

(A).Feature of 400T injection molding machine:

Space between tie brs: 725*725mm

Maximum mould thickness:850mm

Minimum mould thickness:280mm

It can be customized based on your requirements.

(B).The main parameters of this injection moulding machine:

Space between tie brs: 725*725mm

Plastic shot volume 1060,1235,1412,1607g

Screw diameter 65,70,75,80mm

Plastic pressure radio 211,182,158,139Mpa

Screw speed 0-185rpm

Weight 15000kg

Die edge 4000kN

Die stroke to open 700mm

Main motor power 37kw

Overall dimension 7500*1860*2420mm
