GD-170T Injection Moulding Machine/Injection Machine/Molding Machine

GD series of auto plastic injection machine are with Injection weight 45-3590g and Clamping Force 50-680tons. LCD computer control, Famous-brand of hydraulic/electrical/sealing system. They areavailable to injection molding of various thermoplastics such as PC, PP, PE, Nylon, A.B.S.PET.PVC etc. And can produce all kinds of medium-or small-size plastic articles and daily-use commodities

Competitive Advantages of the product

* Top class quality

* Excellent human resources

* Prompt delivery schedules

* Value for money

* Transparent trade practices

1.automaticdouble proportional valveposition transducer duplex pump

2.If hydraulic core pulling device is required,extra charge is neededEach will take you1500 more

3.Freight is not included

4.Variable displacement pump takes 15000 more for ecah setServo-energe saving series 50T-150T each set will cost 25000 more150T-350T each costs 45000 more

5.It can be customized based on your requirements.May be extra charge will be needed in that case

(A).Feature of 170T injection molding machine:

Space between tie brs: 460*460mm

Maximum mould thickness:500mm

Minimum mould thickness:175mm

It can be customized based on your requirements.

(B).The main parameters of this injection molding machine:

Space between tie brs: 460*460mm

Plastic shot volume 283,350,407g

Screw diameter 40,45,50mm

Plastic pressure radio 215,169,137Mpa

Screw speed 0-175rpm

Weight 5200kg

Die edge 1700kN

Die stroke to open 430mm

Main motor power 15kw

Overall dimension 4700*1350*2150mm
