10 Mpa Horizontal Directional Drilling MachineClamp Shackle Device

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Master Core & Core-XZ		Place of Origin	China
Model Number	FDP-245

Delivery Time:10 working days after received your payment
Certification:ISO API

10 Mpa Horizontal Directional Drilling Machine Clamp Shackle Device

pecifications

Trenchless horizontal direct drill FDP-245 is especially for underground pipe laying, and with 2450KN pull back capacity.

Trenchless horizontal direct drill FDP-245 Technical Information
Feed (move) Drive		Drill Tools
Max. Feed/Pull Capacity	2450 KN	Drill Rod	51/2″
Feed/Pull System,Pinion-rack Type, 4-gear-driving Move		Clamp Shackle Device
2-gear Stepless Speed Regulation		Distance adjustable with accurate, stable and reliable breaking-out
Gear I	9m/min.	Shackle centering by itself; Clamp full stroke moving
Gear II	28m/min	Max Make-up Torque	90000N.m
Rotary Drive		Max Break-out Torque	180000N.m
Rotary System: Gear Driving Stepless Speed Regulation		Penetration Angle of Mast	8-16°
Torque of Gear I	70000N.m@42r/pm	Hydraulic System
Torque of Gear II	35000N.m@84r/pm	Rotary sliding closed system, auxiliary loop adopts open type load sensing system
Length of Mast & Drill Rod		Environmental Standard & Service
Customer’s Choice		Engine emission and noise meet the EURO II standard.
Engine		Repair service is available in main cities for main spares.
Manufacturer	Weichai Power	Hydraulic Mud Pump (Optional)
Rated Value	2x450kw(2 engines)	Full Hydraulic Driving, Stepless Adjustable Flux
Operation State	Feed/Pull/Rotation all reach above–mentioned performance index.	Pressure	10Mpa
