25mm Thermal Resistant Green Fabric Wrapped Acoustical Wall Panels For Classroom

Description

The tiles are manufactured from high density fiberglass wool. The visible side is warpped with decorative fabric and the back is covered with normal fiberglass tissue. The four edges can be square or bevel.

Main characteristic:

No sagging, warpping or delaminating

Green building material

Excellent sound absorption

Various designs and colors for decorative fabric are available.

Dimensionally stable under high temperature or humidity.

Remarkable thermal insulation property, energy-saving material

Easily install and adjust

Technical Data:

Applications:

It is recommended that the tiles be installed to the opposite two walls to control the echo of the surroundings. The tiles are widely used in hotels, meetings rooms, music rooms, offices, classrooms, shopping rooms,etc., where have special request for sound absorption.

Size:

600*600*25mm

600*1200*25mm

600 X 2700*25mm

?Dimensions can be ordered upon customer’s requests.

Installation method:

Place?top?edge?on?set?line.?Carefully?swing?bottom?edge?to?meet?impaler?heads.?With?the?panel?resting?on?

the?impaler darts,?apply?in?towards?wall?and?doenward?pressure.

Competitive Advantage:

Fire-resistant: As fiberglass consists of rock fibers, which are combustible. So both basic board and decorative facing of Ecopan panel has achieved Class A fire-resistant property, which has tested by National Authority of China.

Thermal-insulation: Block off the colds outdoor and prevent hear from spreading in or out from indoors. It can make energy-saving and also to create a quiet and comfortable environment.

Humidity: Dimensionally stable in high humidity, no sagging, warpping or delaminating compared with normal wet-craft made mineral wool acoustical panel.

Elegant: Standard quiet white facing, personalized designs will give you a fashionable and comfortable visual feeling. Also other various colors can be ordered.

Cleanability: Special painting on the facing make Ecopan fiberglass panel can be longtime used and seldom absorb dust or Vacuum. You can clean the face with eight wet or dry mop.

Environmental: Fungi and stains resistant, no pollution. It is a new kind of green and healthy building material. Fully recyclable.

Safety and Convenience: No safeguards are needed for the insulation. The working site will still keep clean and tidy as no fibers will fall off. Either exposed or concealed grids are available for the installation. Because of the light weight, the panels are widely used in constructions with large spans in space, such as gymnasiums, exhibition halls, shopping centers, etc. They are easy to trim and install.

?Test Report:

1)The Specific Activity of Radioactive Nuclide:
226RA is undetected;
232Th is undetected;
40K is 28.3Bq/kg

2)Visible Reflectance:
Visible Reflectance result is 0.89?

2)Sound absorption coefficient:
NRC=0.85???
