High Performance Household PV Grid Tied Solar Power System 110V - 240V

Brand Name	ZOCEN		Place of Origin	China
Model Number	ZCGT-1KW

Delivery Time:5-10 days
Certification:CE,CQC,IEC,TUV,CEC,MCS,CHUBB, ISO9001

Items	1KW Grid tied solar power system	Load power	1000W
Application	Home	Solar Power	1000W
Output Voltage	110V-240V	Warranty	25 years

PV Solar Grid Tied System, Rooftop, 1KWp Solar System For Home

1> Quick Detail:

Place of Origin: China Brand Name: ZOCEN Model: ZCGT-1KW Certificate: CE, CQC, IEC, TUV, CEC, MCS, CHUBB, BV, ISO9001

2>Description:

Solar Panels	4pcs, 250W Polycrystalline panels
Inverter	single phase 1KW outdoor on grid inverters
Bracket	aluminum bracket one set
DC Switch	Air Isolator 600V
AC Switch	Air Breaker 440V
Monitor	WIFI Plug
Ground Earth Cable	6sqmm
Ground Earth Clamp	Copper with screws
Cable	4/6 S.q.mm one set
AC power	1000Watt
Nominal AC voltages	110V-240V
Nominal AC frequency	50Hz/60Hz
Efficiency	96.50%
Euro ETA	95.50%

3> Features:

One-stop service from components to logistics High-efficiency solar modules included Provides long term and reliable power performance With over-voltage, low and overload protection Easy-to-install Fast and accurate delivery; no waste and waiting time Free pre-sale technical support, including system design Long service lifespan: Zocen Solar confirm that our solar panel will last for at least 25 years, 5 years warranty on material and workmanship, and guarantee the output will be 90% after 10 years.

4> Our Services

Designed for low-light and highly exposed locations Quick and low cost to deploy Rated from -35 to 85°C (operational) Industrial electrical infrastructure designed for seamless integration with existing systems NEC code compliant over current, lightning protection and safety disconnect Solid-state electronics TUV/IEC/CE listed components Designed for environmentally challenged locations 25 years solar module warranty and full system warranty Zocen Solar benefits: Take control of and reduce your business\' monthly electricity bills Work with the best solar team in the industry with exceptional service Finance capital expense with Solar Leading leasing, loan financing and government credit programs Deploy best-of-breed solutions targeted for your specific solar exposure and facility requirements

5> Components details

Solar panels: with 25years lifetime 12years warranty, with CHUBB insurance guaranteed. Only use A grade solar cells. Positive tolerance.

	Maximum Power	250
Power Tolerance	±3%
Open Circuit Voltage(Voc)	37.30
Short Circuit Current(Isc)	8.73
Maximum Power Voltage(Vmp)	30.10
Maximum Power Voltage(Imp)	8.31
Module Efficiency	15.37%
Max. System Voltage	1000VDC
Solar Cells	Polycrystalline156*156mm(6 inch)
Cells series	60cs(6*10)
Bypass Diodes	6pcs 12A
Temperature Coefficients of Pmax	-0.47%/°C
Temperature Coefficients of Voc	-0.33%/°C
Temperature Coefficients of Isc	0.05%/°C
NOTC-Nominal Operating Cell Tepm.	45℃(±2°C)
STC Condition	1000W/m2, AM1.5, 25°C

One phases grid tied inverter--2KW High performance string inverters Easy and affordable to install Full featured inverter display and communications

Input ( DC side )250
