Automatic Double Chamber Tea Bag Packing Machine

//Application: //

It is suitable for double chamber tea bag products packing, such as broken tea, coffee, ginseng essence, diet tea, health care tea, medical tea and herbal tea, etc.

//Features: //

1.This can automatically complete bag making, filling, measuring, sealing, thread feeding, tag attaching, cutting and counting etc. It would highly improve the working efficiency and reduce labor expense.

2.Pins only need to be stapled by hand.

3.PLC control system and automatic temperature control system are adopted, which can effectively control the sealing temperature within the standard range.

//Technical data://

Machine type: Tea Bag Packing Machine Series

Machine model:  C13

Machine name: Automatic Double Chamber Tea Bag Packing Machine

Packing material: Filter paper, Thread, Tag

Measuring:    Measuring cup filler

Filling range: 3-15ml

Bag size: L:150mm (80 +70 mm, bi-fold double chamber bag);

W:40mm.  Similar to "Lipton" tea bags.

Filter paper width: 87mm

Tag size: L:20mm , W:25mm

Thread length: 155~200mm

Packing speed: 20~40 bags/min

Power supply: 220V/50HZ/1.6KW

Machine dimension: 900*950*1800mm(L*W*H)

Machine weight:    350KGS
