10T / h Water Treatment Equipments , Water Treatment Machine

A, the raw water tank

A water storage capacity: 10T 1 Taiwan

2, Material: PE

B, the booster pump

1, Model: CHL16-20

2, Material: 304 stainless steel

C, the mechanical filter

1, flow: 10T / h

2, Specification: ￠ 1000 * 2550

3, Material: 304 stainless steel (wall coated with epoxy resin)

4, the connection pipe, the valve member: PVC-U

5, quartz sand: 1000Kg

D, the activated carbon filter

1, flow: 10T / h

2, Specification: ￠ 900 * 2450mm

3, Material: 304 stainless steel (wall coated with epoxy resin)

4, the connection pipe, the valve member: PVC-U

5, activated carbon: 450Kg

E, precision

1, flow: 10T / h

2, Specification: ￠ 400 * 1600mm

3, Material: 304 stainless steel

4, folded filter: 750mm long, 16

F, hollow fiber ultrafilter

1, flow: 10T / h

2, Size: 1500 * 900 * 1700mm

3, the external pressure polysulfone ultrafiltration membrane: 6 \"5, 304 stainless steel booster pump 1, stainless steel wash tank a drug, PVC-U connecting pipe, valves, 1 set of gauges 1, flowmeter 1 a

G, the ozone generator (with 1m3 / h Oxygen)

1, the amount of ozone: 50g / h

2, Dimension: 800 * 500 * 1000mm

3, Power: 500W

H, storage tank

A water storage capacity: 8T (2000 * 2600mm)

2, Material: 304 stainless steel

I, PVC-U systems connecting pipe, valves 1 set
?
