Oxygen Permeation(OTR) Test System

Oxygen Permeation Test System is applicable in the oxygen permeation testing of plastic films, high barrer materials, solar energy backsheets, sheets, laminated materials, aluminizer, coextrusion and foils as well as bottles, pouches, jars and boxes made of plastic, rubber, paper, glass and metal materials.

Oxygen Permeation Test System conforms to ASTM F1307, ASTM D3985, ASTM F1927, ISO 15105-2, JIS K7126 etc.

Features:

1. Computer control with both films and containers test types.

2. Three testing chambers integrated in one block.

3. One master base can connect 9 satellite modules; thirty specimens testable simultaneously;

4. Mixed testing control for oxygen and water vapor transmission rate

5. Test process will not be influenced by power off

Technical Data:

1.For Film;

Test Range:0.01~6500cm3/m2•day(Routine)

           0.07~65000cm3/m2•day (Optional)

Resolution: 0.001 ml/m2•day

Temp. Control Range: 15℃~55℃(Routine)

Humidity Control Range: 0%RH; 35%RH~90%RH; 100%RH

2.For Container;

Test Range:0.0001~60 cm3/pkg•day

Resolution: 0.00001cm3/ pkg•day

Temp. Control Range: 15℃~55℃ (Routine)

Humidity Control Range: 0%RH; 35%RH~90%RH; 100%RH

For more information, please feel free to contact Shirley via:
TEL: 0086-531-85061080
