Industrial Vacuum Cooling Equipment With Schneider / LS Electrical Parts

Industrial Vacuum Cooling Equipment With Schneider / LS Electrical Parts

Vacuum Cooling System?Brief Description

Vacuum cooling is the quickest and most cost-efficient cooling system for vegetables, fruits, flowers & more. The vacuum cooling technology, which can strongly improve your product quality and at the same time reduce your cooling costs, is now becoming an acceptable investment for almost all vegetable growers!

After the product is harvested and packaged, it is placed on pallets for shipping. The pallets are loaded into a vacuum tight chamber and the process begins. The equipment drops the pressure inside the vessel by removing air through vacuum pumps. Once the level of vacuum reaches the "flash point" moisture and heat are removed from the product in the form of water vapor. The lower the pressure inside the chamber, the lower the boiling point of water. As the vacuum goes deeper, more water vapor is removed and the product temperature is reduced until the desired temperature is achieved.

Vacuum Cooling System?Main Components

a. Vacuum chamber--To load your vegetables. The size of the chamber is defined by the amount of pallets you want to cool at the same time, and their individual dimensions. The size of the chamber will decide the number of vacuum pumps to be used.

b. Vacuum system--To takes away the air in vacuum chamber, then cool the vegetables down. For the vacuum we are using pumps of the market leaders Busch and Elmo Rietchle. These pumps hardly need maintenance, are reliable and make very little noise.

c. Refrigeration system--To catch the water vapor in ths chamber so as to ensure the continous cooling process.

The evaporator (water catcher) inside the vacuum chamber condenses the water vapour, and ensures only dry air leaves the vacuum chamber towards the pumps.
Outside the chamber, the cold medium (R 404a) is cooled down by a refrigeration system. The compressor needed for this heat exchange process is supplied by Bitzer (Germany) or by Hanbell (Taiwan).

d. Control system---To control and show the working condition of the vacuum cooling System.

Broccoli Vacuum Cooling System?Features

1. Cool the products to 0-5 degrees in 30 minutes

2. Uniform cooling style.(the core and the surface reach exactly the same temperature)

3. Very low water loss rate of 1.5-3%.

4. Cure the surface demage of the vegetables and stop their worsening.

5. Energe cost saving because of high efficiency.

6. Never frozen delicate vegetables.

Broccoli Vacuum Cooling System?Advantages

1. Minimized production losses

2. Improved economic of harvest operations

3. Minimized losses during marketing

4. Improved utilization by consumer

5. Expanded market opportunities

Vacuum Cooling System?Application Field

1. Vegetables(All Leafy Vegetables/Broccoli/Cauli Flower/Mushrooms/Sweet corn/ etc.)
2. Flowers(Fresh cut flowers)
3. Fruits(Berries/Cherries etc.)

Vacuum Cooling System?Models&Specifications

Customized Options of Our Vacuum Cooling System

1. Condensor Options: Air cooling/Water cooling /Evaporative

2. Function Options: Hydro system&Water spray system

3. Door Option
