Fingerless Single Facer II
- T/T L/C D/P D/A
- 7 days
Product Details
| Place of Origin | China |
Product Description
Application:
1. Adapt to middle and high speed production line .Computer control model adopts advanced PLC control with touch screen.
2. Adopt in-draw structure with silencer.
3. Electric adjust glue thickness, digital display. There is automatic adjustment for option.
4. The diameter of corrugating roll is Φ260mm、Φ310mm、Φ360mm、
Φ 430mm made from alloy steel 48CrMo. Hardened treatment to its surface, precision grinding, coated with chrome , hardness can reach HRC58-62.
5. The working surface of each paper-guiding roll, preheater and pressure roll is polished and coated with chrome.
6. Automatic, interval, circular lubrication and high temperature lubrication grease for option.
7. Adopt infrared detector, auto paper break protection, when paper breaking, the press roll and the glue plate will be back.
Specifications
1. Max. speed: 250m/min
2. Width: 1400mm-2500mm
3. Flute: A, B, BC, E, F
