High Brightness Traffic LED Warning Signs With Module Dimension 320mm X 160mm
- T/T L/C D/P D/A
- 7 days
You May Like
-
Dual Color P20 Full Temporary Traffic Control Signs With Module Dimension 320mm X 160mm
-
Aluminium Frame P16 Led Traffic Calming Signs With Beam Width V35/H70
-
Full Color P16 LED Traffic Control Signs With 7440nits luminance / 600W/ Power Consumption
-
Programmable HD P31.25 Changeable Message Boards With Power Consumption
-
Traffic Electronic P20 Full Color Variable Message Signs Solar Road Signs For Road
-
RGB P20 High Way Traffic Management Signs With Storage Memory At A Time
Product Details
| Brand Name | YAHAM | Place of Origin | China | |
| Model Number | VMS |
Product Description
Certification:CE/ FCC
P20 1R1G1B Full Variable Message Sign With Module Dimension 320mm x 160mm
Specifications:
| Technical Parameter | LED TYPE | SMD LED |
| Pixel Pitch | 20mm | |
| Pixel Density | 2500 pixels/sqm | |
| Pixel Configuration | 1R,1G,1B | |
| Module Dimension | 160mm(H)X320mm(W) | |
| Module Resolution | 8x16 Pixels | |
| Cabinet Dimension | 960mmx960mmx210mm | |
| Cabinet Resolution | 48x48 pixels | |
| Cabinet material | Aluninum alloy | |
| Best Viewing Distance | 33m-300m | |
| Gray scale | 8Bit/256evels | |
| viewing angle | V12°/H30° | |
| Dimming Level | 32 | |
| Luminance | 12400nits | |
| Electric protection | Overload protection and short circuit protection | |
| Maintenance | back access | |
| Color | Full-color | |
| Max. power consumption | 300W/M2 | |
| Operating temperature | -20℃-60℃ | |
| Operating Relative | Humidity:95%RH(Max.) |
Description:
1. With design of optical lens, the VMS can have high brightness and low power consumption;
2. Optional Full color VMS, Dual color VMS and Single color VMS;
3. Optional pixelpitch:16mm,20mm,25mm,31.25mm;
4. Solar power supply system available;
5. Auto dimming control system. It can adjust the brightness of the VMS according to the environment brightness, automatically being energy saving;
6. Support Global Positioning System(GPS);
7. Support Both 12v-24v and 220v power supply;
8. Our system has the inspection on the voltage of the batteries , also we have over-charge protect system. The precaution alarm will sent feedback. In this way, the batteries will work under well protection;
9. Support local control and remote wireless control;
10. Fans-free design can reduce the maintenance rate.
Applications:
| used for the traffic warning information of road & bridge construction, fire-fighting, parking lots,ect. |
Competitive Advantage:
Applying the solar power supply system can offer a longer service time. Yaham Extreme energy saving LED sign work with the unique energy saving technologies, the new lowest level has been complete. Not only can maintain the high brightness of the display information, but the display time can be extended.
