Home > Products > Variable Message Signs > Outdoor Scrolling Variable Message Signs Single Pillar Long Life Span
Outdoor Scrolling Variable Message Signs Single Pillar Long Life Span
- T/T L/C D/P D/A
- 7 days
You May Like
-
P16 Full Matrix Airport Passenger Information LED Moving Sign VMS Modules Assembled
-
Full matrix P25 Variable Message Signs Esay Transportation with Module Design
-
High Resolution Electronic Message Boards , P31.25 Road Traffic LED Warning Signs 12400cd/M2 In Whit
-
Dual Full Mtrix Portable Road Signs , Led Moving Message With Optical Lens
-
High Brightness Traffic LED Warning Signs With Module Dimension 320mm X 160mm
-
Dual Color P20 Full Temporary Traffic Control Signs With Module Dimension 320mm X 160mm
Product Details
Brand Name | YAHAM | Place of Origin | China | |
Model Number | YH-KXB-L-D25 |
Product Description
Certification:CE/FCC/ GB23828-2009/EN12966/NTCIP
Outdoor Scrolling Variable Message Signs Single Pillar Long Life Span
Advantages
The door frame type changeable message sign can receive messages from the monitoring and management computer, can display Chinese, English, Uighur language, numbers and icon etc. Its control unit can save more than 100 message, can be invoked by the operations clerk at any time, and can be edited, tested and controlled by the clerk on the computer.
Specifications:
Technical Parameter? | Panel Size | D25 ?variable message sign |
Aspect Ratio
LED type |
SMD |
|
Pixel Pitch |
25mm |
|
Pixel Density |
1,600 pixels/sqm |
|
Pixel Configuration |
3 in 1 SMD Led with Lens |
|
Module |
200mm x 200mm |
|
Module Resolution |
8 x 8 pixels |
|
Screen Weight |
Approx.: 65kg/sqm |
|
Viewing Angle |
H 10 Deg. / V 30 Deg.(EN12966: B6) |
|
Best Viewing Distance |
12m+ |
|
Maintenance |
Rea/Front Access |
|
Brightness |
12400nits(EN12966: L3) |
|
Colour |
EN12966: C2 |
|
Storage Medium | Flash memory card | 2gb to 36gb for the capacity |
Support Ad files | Video formats | MP4(AVI:DIVX/XVID),MPG2(DVD:VOB/MPG2), MPEG1 (VCD: DAT/MPG1) |
Audio formats | MP3 | |
Photo formats | JPG | |
OSD Language | English, Chinese, French, German, Italian, Spanish,Arabic | |
Power supply |
Max. 280W/sqm; Avg. 100W/sqm |
|
Storage Temperature | -40°C~80°C | |
Normal Working Temperature | -20°C~60°C |
Description:
1.?Clear vivid image quality even in direct, full-on sunlight to ensure you attracts more audience to get short ROIof your LED display screen's investment.
2.?Convenient Servicing: Front and rear cabinet access make the maintance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.
3. Higher Protect Level:Sealed by epoxy glue,IP65 certificate,highly wind resist,dust resist and corrosion proof.
4. Easy Installation:it can be easily installed with the screws and nuts.
5.?Energy Saving & Environment Protection:solar energy powered system,100% clean energy.
Applications:
road & bridge construction |
Competitive Advantage:
Variable message sign?is one of the most important elements in the traffic management system, by issuing a notice, warming information on the Variable Message display to guide driver pay attention to the traffic. Our variable message signs are made as per EN12966 standard’s requirement so as to ensure better legibility of the display.
