Led Obstruction Lights Red Night Flashing 40 Fpm Failure Alarm With Control Panel
- T/T L/C D/P D/A
 - 7 days

You May Like
-


Red / PC Lens UV Stabilized Led Aviation Obstruction Lights for Top Building
 -


IP65 Offshore Air Obstacle Light 10W Red Night Flashing Synchronized by GPS
 -


GPS Synchronized Aviation Obstruction Light 40 Fpm Red Night IP65 for Wind Power
 -


High Intensity Type A Airport Obstruction Lights in Malaysia Kuala Lumpur Tower
 -


24 Hours Aviation Obstruction Light White Flashing for Broadcast Towers
 -


5W Aircraft Obstruction Light 168mm 280mm 80m/s Wind Speed ISO9001

Product Details
| Brand Name | PLUSAFE | Place of Origin | China | |
| Model Number | OB66 |
Product Description
Certification:ISO9001, ICAO, CAAC
Led Obstruction Lights Red Night Flashing 40 fpm Failure Alarm with Control Panel
Specifications:
| Parameter | |
| Light Characteristics | |
| International standard |
			 FAA L864 ; ICAO Annex14 VolumeI;Chapter6 FAA AC150/5345-43G L864  |
| Light source | LED |
| Color | Red |
| Lifespan of LED | 100,000hours (decay less than 20%) |
| Light intensity | Compliance to ICAO Annex14 photometric; 2000cd |
| Photo sensor sensitivity | 50Lux |
| Flash frequency | 40 fpm |
| Vertical Angle | 4° |
| Electrical Characteristics | |
| Operating Mode | 110V to 240V AC; 24V to 55V DC available |
|
			 Power Consumption  |
			10W |
| Physical Characteristics | |
| Body/Base Material | Casting Aluminum, aviation yellow painted |
| Lens Material | Polycarbonate UV stabilized,good impact resistance |
|
			 Overall Dimension(mm)  |
			φ210mm ×140mm |
|
			 Mounting Dimension(mm)  |
			126×126-4×φ11mm |
| Weight(kg) | 3kg |
| Environmental Factors | |
| Ingress Grade | IP65 |
|
			 Temperature Range  |
			-55℃ to 55℃ |
| Wind Speed | 80m/s |
| Quality Assurance | ISO9001:2008 |
Description:
1. It is used increase conspicuity of structures or obstructions during nighttime.
2. Also, with strong metal body, the light is easy to deploy to almost any condition and any emerge.
3. Robust body built provides good protection against hash environments.
4. It is working under flash mode based ICAO requirement. Users can specify steady burning / 24 hours flashing mode for purchase requirement.
5. DC or AC wide range operating voltage 110V to 250V AC, 24V to 55V DC.
6. Portable structure, very easy to mounting.
7. Cast aluminum base and painted.
8. Polycarbonate lens of strong impact resistance, good light transmission.
9. Optic reflector design makes beams more concentrate, effective and further.
10. Light source using Cree LED with an expectancy lifespan 100,000 hrs above.
11. Built in surge protection device, can be used in the harsh environment.
12. GPS synchro function available.
Applications:
| High-rise building marking |
| Telecom & broadcast |
| Bridge |
| Navigation aid |
| Port |
| Power plant |
| Wind power |
| Crane machines |
| Airfield lighting |
Competitive Advantage:
PLUSAFE SOLUTIONS LIMITED (P.S.L) providing reliable and costing products and services. Based on our experienced technical teams and qualified factory the lights are manufactured followed by ICAO, FAA and relevant regulations. We value our customer needs and honesty?is 1st in our culture.
Supply all range of aviation lights and customize service. Focus on LED Technology Solutions development. Reasonable price and good service.Contact Us
