8 Port Passive POE injector

8 Port 10/100M Passive PoE Injector

Technical specifications
 Panel 8 integrating passive POE injector suitable for powering up to eight devices.

 The RJ45 connectors on one side are connected Ethernet ports with no power (switch) on the opposite side of the device used to connect power for Ethernet cable.

 Are used to power the two unused pairs of the Ethernet cable.
 Power couples: 4,5 (positive pole) / 7,8 (negative pole)

Product Specifications/Features

It is the 8 port passive POE injector hub. By using different power adaptors, it can flexibly supply 24VDC or 48VDC for most popular POE devices, such as wireless AP, IP CAM, or IP Phone. it offers both DC Jack (5.5*2.1mm) and terminal block (2 pins) for diverse power inputs and is convenient to install on desks or walls by mount holes.

FEATURES

* Economic POE solutio
* Detecting output power (30W Max)

* Flexible power (DC: 24V or 48V)

* Supporting 10/100Mbps

* Power indication by LED

* Easy installation

MARKETS

? Remote routers, access points, and bridges

? Remote networking equipment

? Remote camera systems

? 400 MHz to 10 GHz systems

? SOHO equipment

? IP phone systems

? WiMAX

Customized designs are welcome.

OEM orders are also accepted.

The poe injector does not include the power supply.

The power supply is sold seperately.

Note: this module does not provide proper, standards-compliant 802.3af PoE support. But it's a whole lot cheaper, and works with just about any PoE system.
