Non Spillable GEL 12V 55AH Solar System Battery for Medical Equipments

Non Spillable GEL 12V 55AH Solar System Battery for Medical Equipments

Specifications:

Description:

● Designed life for floating charge is 5 - 8 years (20℃);

● Float charging voltage: 13.5V – 13.8V (20℃);

● Such as broadband, PVs etc through up-to-date gel technologies.

● Wide temperature scope of application (-15~45℃);

● Best temperature of application (20±5℃);

● No leaking, safe and reliable;

● Good deep charge cycle performance;

● Good over-discharging recovery performance.

● Standing or lying down for using, convenient to transport and install;

● Our gel batteries uses German origin high purity fumed silica to form sulfuric acid thixotropic Gel and fills to the batteries with vacuum to ensure the fully penetration of electrolyte through separators and plates pastes.

● Low self-discharge rate.

Applications:

● UPS & EPS system

● Telecommunication

● Banks & Financial Centre

● Medical Equipments

● Emergency Power System

● Alarm & Security system

● High Power Backup Supply

● Control System

● Wind Energy System

TECHNICAL FEATURES:

? Sealed Construction

The unique construction and sealing techniques of the battery guarantee leak proof operation in any position with no adverse effect to capacity or service life.

? Electrolyte Suspension System

All batteries utilize an electrolyte suspension system consisting of a high porosity, glass fiber material which in conjunction with plates, totally absorb and contain the electrolyte.

? Gas Recombination

CGB batteries incorporate a built-in design that controls gas generation and induces recombination of more than 99% of gases generated during float or cyclic usage.

? Maintenance Free Operation

There is no need to check specific gravity of the electrolyte or add water to batteries during float service life. In fact, there is no provision for this type of maintenance.

? Low Pressure Valve Regulated System..

All batteries are equipped with safety release valves, designed to operate between 1.5 and 6 psi (10-40kPa) and automatically reseal. Hence, there is never an excessive accumulation of gas within the battery.

? Heavy Duty Grids

Heavy duty lead calcium tin alloy grids provide an extra margin of performance and service life in either float or cyclic applications.

? Float Service Life

GEL Series batteries have an expected life span of 5 to 8 years in float service applications.

? Self Discharge - Shelf Life

The self discharge rate at room temperature is approximately 3% of rated capacity per month.

? Operating Temperature

CGB Batteries may be operated over a broad range of ambient temperatures.

? Deep Discharge Recovery

The batteries recover their capacities even after repeated deep discharges.

QUALITY ASSURANCE

1. Raw material control: Any raw material will be forbidden used in the production if they didn't pass the testing by laboratory strictly.
2. Production process control: The semi-finished products must pass several inspections in the production line.
3. Finished products control: The finished battery must be tested 100% by four function testing machine and pass the inner resistance testing, density testing, OCV,CCV. before packaging.
4. Shipment control: The goods can't be sold unless their appearance and performance are tested 100% by the professional inspector.

Environmental Services:

? Ensure that our operations and products meet or exceed government requirements.

? Monitor, control and eliminate, where possible, all environmental emissions, discharges and waste generated by our operations.

? Develop products that will have a minimum effect on our environment.

General Features:

● 23 years manufacturing sealed lead acid storage battery in China
● Excellent recharge and discharge performance;

● ISO9001, ISO14001, OHSAS18001, CE, UL, VDS Certificates

● Good prices due to our own plate producti
