HDMI Switch Box With Audio Out , HDMI 1.4 Switcher Support Multiplexed HDMI 4 Input

HDMI 1.4 Switcher HDMI Switcher box 4 by 1 Switcher Support multiplexed HDMI 4-input

1 . Introduction

This is a high performance 4x HDMI and 1x HDMI output switcher with digital/analog audio outputs. It supports HDCP repeater functions and fast switching between any of the four of HDMI input ports. The system supports all 3D TV formats in addition to all HDTV formats up to 4Kx2K. Furthermore, the remote control gives uses complete control over the selection of sources and makes the device incredibly user friendly.

2 . FEATURES

1 . Support multiplexed HDMI 4-input.

2 . Compliant with HDMI 1.4a, CTS 1.4a, DVI 1.0 & VESA DisplayPort 1.1a standards.

3 . HDMI 1.4 support: 3D TV support, CEC1.4.

4 . HDCP repeater support.

5 . Support 3D Video & 4Kx2K, 8, 10, 12 & 16 bits per color depth.

6 . Audio support:

7 . HDMI 1.4 compatible audio interface

8 . Dedicated, flexible audio input/output port

9 . Dolby TrueHD

10 . DTS-HD Master Audio 7.1CH

11 . Full audio input and output support

3 . PACKAGING ACCESSORIES

4 . Specification

5 . Operation controls and Fuctions

Front Panel

1 . ON/OFF: Power on/off switch.

2 . IN1,2,3,4 LED: These red LED illuminate when the output select to the corresponding input.

3 . 2.0,5.1,7.1 LED: These red LED illuminate when the audio EDID select to corresponding audio.

4 . IR : Remote control receiver.

5 . AUDIO BUTTON: Press this button to select the 2.0CH,5.1CH,7.1CH audio output mode.

6 . Input BUTTON:Press this button to select the input source.

Rear Panel

1 . Input Source: These slot is where you connect the HDMI or Display Port source output from DVD, PS3,Set-top Box and Note Book.

2 . HDMI OUT: This slot is where you connect the HDTV or monitor with HDMI cable for input source display.

3 . DC IN: Plug the 5V DC power supply into the unit and connect the adaptor to AC wall outlet.

Left Panel

1 . AUDIO OUT: This slot is where you connect to the speaker with 3.5mm earphone cable.

2 . SPIDF OUT: This slot is where you connect to the amplifier with optical fiber cable.

6 . Remote control

7 . Application Example

Services:

1)Thank you for purchasing our product. To ensure safety and many years' trouble-free operation of the product, please read the manual carefully before using this product.

2) We will 24 hours online to services you ,if there any problem just contact us at :Jessie@dodonet.com.cn or call:86-137 1442 9421.
