100T Welding Turning Rolls With Double Driving Way and Bolt Adjustable
- T/T L/C D/P D/A
- 7 days
You May Like
-
Pipe / Vessel Welding Turning Rolls 60T for Freezing Equipment
-
Driving / Idler Welding Turning Rolls 40T For Boiler Industries
-
20000 Kg Bolt Adjusting Welding Turning Rolls For Tank / Pipe Welding
-
2500mm - 5000mm Dia. Wind Tower Production Line 60T For Power Station Construction
-
Baffler Assembly Box Beam Welding Machine For Box Beam Production
-
U / Box Beam Welding Assembly Machine 300 x 300 - 1200 x 1200mm
Product Details
| Brand Name | H-WELDING | Place of Origin | China | |
| Model Number | XHGK-100 |
Product Description
Certification:Certification of original
Double Driving Way Bolt Adjustable 100T Welding Turning Rolls Φ500 × 120mm Wheel
Quick Detail:
This series roller-bed features is auxiliary equipment for automatic welding. The bolt adjusting turning roller is suitable for circular pipe/tank/vessel welding. The powered turning rolls adopt double driving way, two rollers are driven by two motor via reducer separately. There are several specifications for customer choice; we also can special design according to customer’s requirements.Description:
This series of roller-bed consists of driving roller, idler roller and electric system etc.
The distance between the powered turning roll and idle roll is adjusted by the bolts to suit for the work piece different diameter, ensuring surrounding angle of work-piece between 45°～110°, which is convenience and easy. The equipment features in good adaptation, smooth revolve, VFD adjustable revolve speed and displaying in linear speed, which is suitable for welding, polishing, assembly for pipe/tank/vessel longitudinal and transverse seam welding.??
Applications:
It used in many industries such as pressure vessel, boiler, freezing equipment, power station construction, metallurgical, engineering machinery, marine building, and petro-chemical industries etc.
Specifications:
|
Type |
Max loading (kg) |
Range of suitable work piece(mm) |
Dia. and width of the wheel(mm) |
roller linear velocity(m/h) |
Power of motor(kw) |
Adjustable mode for space |
Way of setting |
|
|
Rubber rollers |
Metal rollers |
|||||||
|
HGK-2 |
2000 |
Φ200-1200 |
Φ200×100 |
2×Φ190×16 |
6-60 |
2×0.18 |
Manual screw adjustment or bolt shift |
AC converter stepless speed adjust |
|
HGK-5 |
5000 |
Φ250-2300 |
Φ250×100 |
2×Φ240×20 |
6-60 |
2×0.37 |
||
|
HGK-10 |
10000 |
Φ300-2800 |
Φ300×120 |
2×Φ290×25 |
6-60 |
2×0.55 |
||
|
HGK-20 |
20000 |
Φ500-3500 |
Φ350×120 |
2×Φ340×35 |
6-60 |
2×1.1 |
||
|
HGK-40 |
40000 |
Φ600-4200 |
Φ400×120 |
2×Φ390×45 |
6-60 |
2×1.5 |
||
|
HGK-60 |
60000 |
Φ750-4800 |
Φ450×120 |
2×Φ440×60 |
6-60 |
2×2.2 |
Bolt shift |
|
|
HGK-80 |
80000 |
Φ850-5000 |
Φ500×120 |
2×Φ490×70 |
6-60 |
2×3 |
||
|
HGK-100 |
100000 |
Φ1000-5500 |
Φ500×120 |
2×Φ490×100 |
