Wide Viewing Angle Indoor P6mm Rental LED Screens for Exhibition Hall
- T/T L/C D/P D/A
- 7 days
You May Like
-
Customized Free Splicing P4mm Rental LED Screen for Live Show
-
Custom Outdoor Strip Led Curtain Displays Billboard
-
Custom Outdoor Strip Led Curtain Displays for Advertising P20.83
-
OEM Outdoor Strip Led Advertising Curtain Displays
-
Outdoor SMD LED Bus Display Led Advertising Signs
-
Outdoor SMD Led Bus Display LED Signs Decoration
Product Details
Brand Name | Q-Color | Place of Origin | China | |
Model Number | IDC-6S |
Product Description
Certification:TUV, ETL,UL
Wide Viewing Angle Indoor P6mm Rental LED Screens for Exhibition Hall
Indoor P6mm LED Rental Screen Main Features:
1.hanging beam and cabinet as well as adjacent cabinets are connected and fixed by lock catch ,no need tools.?
2. It saves time and labor costs that each cabinet weighs about 10 kg and 1 person can install 60 cabinets in1 hour
3.Display signal cable and the power cable are of waterproof air plug design,which enables quick and easy installation and removal .There is no cable clutter on the rear surface of the display,which is clean and beautiful.
4.For installation, standard hasp lock is used instead of suspension clasp, which achieves rapid assembly without tools.
Technical Spec
Model | Unit | IDC-3S | IDC-4S | IDC-5S | IDC-6S |
Pixel?Pitch | mm | 3 | 4 | 5 | 6 |
Physical?Density | dot/m2 | 111111 | 62500 | 40000 | 27777 |
LED?Configuration | ? | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
LED?Type | ? | SMD2121 | SMD2121 | SMD3528 | SMD3528 |
Module?Size | mm*mm | 240*240 | 240*240 | 240*240 | 240*240 |
Module?Resolution | w*h | 80*80 | 60*60 | 48*48 | 40*40 |
Module?Weight | Kg | ? | ? | ? | ? |
Driver?Mode | ? | 1/16?Scan | 1/15Scan | 1/12?Scan | 1/10?Scan |
Brightness | cd/m2 | ≥1800 | ≥1800 | ≥1800 | ≥1500 |
Grey?Scale | ? | ≥14bit | |||
Refresh?Rate | Hz | ≥960 | |||
Cabinet?Resolution | w*h | 160*160 | 120*120 | 96*96 | 80*80 |
Max?Power?Consumption | W/m2 | ≤1240 | ≤1040 | ≤720 | ≤860 |
Average?Power?Consumption | W/m2 | 420~620 | 350~520 | 240~360 | 286~430 |
Cabinet?Size | mm | 480*480 | 480*480 | 480*480 | 480*480 |
Cabinet?Weight | Kg | ? | ? | ? | ? |
Viewing?Angle | degree:H | 120o | |||
degree:V | 120o | ||||
Mini?Viewing?Distance | m | 3 | 4 | 5 | 6 |
? | m | 3.8--10 | 5--13 | 6--17 | 8--20 |
Use?Temperature(oC) | Operating(oC) | -20oC?to?+50oC | |||
Storage(oC) | -20oC?to?+50oC | ||||
Input?Voltage?(nomina) | VAC | (100V~240V) | |||
Input?Power?Frequency | Hertz | 50Hz-60Hz | |||
Failure?Rate | ? | <1/100000 | |||
Panel?Input?Format | ? | SDI,RGBHV,YUV,YC,Composite,HDMI,DVI,SD/HD-SDI?ect. | |||
Life?Time | hrs | ≥100,000 | |||
IP?Rate | ? | ? |
Our services
1.Could provide LED display project support and do investigation in local places since our customers start the LED display project budget.
2.Customized LED screen software and hardware products will be provided base on customers’ requirements.
3.Provide LED screen technical training (factory or on-site) for different customers.
4.Drawings like steel structure drawing, connection drawing, etc. can be provided after the order.
5.Timely online services are provided whenever there is software operational problems and we’ll solve problems as soon as possible in working with our customers. ?
6.USA and Netherlands Netherlands exhibition show:ISA,Infocomm,ISE etc.
Cabinet view:
?
Packaging: Plywood or Flight case
Domestic and Overseas Projects:
