Digital Curved LED Screen Rentals / Indoor Rental LED Display SMD1010 With MBI5052 Driving Chip

FOB Price

Negotiable / Meter

1 Meter(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Glux		Place of Origin	China
Model Number	TVsn 1.9

Certification:CE/ROHS/UL/TUV
Digital Curved LED Screen Rentals / Indoor Rental LED Display SMD1010 With MBI5052 Driving Chip

1. Type: indoor rental LED display;

2. Refresh Rate (Hz): 3000;

3.?Color Temperature (after calibration) (K): 6500;

4.?Weight?capacity: 500kg/panel;

5. Application: Indoor TV programs, products release conferences, meeting/summit, celebrations,?etc.

Description:

1. Double power for back-up,double signal for insurance

2. LCD info display on real time: indicating operating time

Product performance and product temprature

3. High definition high precision image performance

4. Black lights ,black mask ,entire blace 1010 LED ,PWM energy saving IC

5. Lamp drive of dividing radiating ,soft and hard combined plate ,FPC+PCB

Main Parameters:

Parameter Type	TVsn1.5	TVsn1.9
Pixel Pitch(mm)	1.5	1.9
Pixel Density (dots/m2)	409600	262144
Pixel/Panel(W*H)	160x160	128x128
Brightness Max(cd/m2)	1000	1000
Grey Scale (bit)	16	16
Refresh Rate (Hz)	3000	3000
Frame Rate(Hz)	30/70	30/70
Contrast	4000:1	4000:1
Scan Mode	1/32	1/32
Color Temperature (after calibration) (K)	6500	6500
Horizontal/Vertical Viewing Angle (°)	H140/V140	H140/V140
Panel Size (W x H x D) (mm)	250x250x58	250x250x58
Module Size (W x H ) (mm)	250x250	250x250
Weight (kg/panel)	2.1	2.0
Protection	IP40	IP40
Power Supply	Single power(Dual Power)	Single power(Dual Power)
Working Voltage(V)	AC100-240V/50/60Hz	AC100-240V/50/60Hz
Max Power Consumption (W/pc)	75	75
Avr Power Consumption (W/pc)	36	36
Working Temperature	-20Co/40Co	-20Co/40Co
Cabinet Material	Carbon fiber	Carbon fiber
Panel weight bearing capacity	500kg	500kg
Signal Cable	CAT5-1000M	CAT5-1000M
Video Signal Input Interface	DVI/HDMI/HDSDI	DVI/HDMI/HDSDI
Life Time (h)	100000	100000

Main Project we have operated with this product:

? ? ? ? ? ? ? ? ? ? ??2015 LV Show Singapore? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ??2008-2016 CCTV Spring Festival Gala
