SS316L stainless steel TUL-20 lobe rotary pump for regulating syrup candy chocolate pharmacy

SS316L stainless steel TUL-20 lobe rotary pump for regulating syrup candy chocolate pharmacy

Description

Options

1.?Mechanical?seal:?SIC / SICE / EPDM,?TC / TC, EPDM

2.?Single?seal,?Double?Mechanical?Seal

3.?Rotors:?2?leave?rotor,?3?leave?rotors,?Butterfly?rotors,?Single?Butterfly?rotors

4.?Gasket:?FPM(Viton),NBR,?EPDM

5.?Relief?valve?at?front?cover?r?external?by?–pass

6.?Built-in?safety?valve

7.?End-face?heat??jacket

8.?Complete?heat?jacket

9.?Vertical?TUR?Series?or?Horizontal?TUL?Series

10.?Different?Drives?and?Fixes?

11.?Assembly?on?a?stainless?steel?baseplate?

12.?Connection:?Clamp(DIN32676,3A,ISO), Threaad(DIN,SMS,RJT,IDF), Butt?weld,?Flange

13.?Motor?Type?B5?motor?frequency?50HZ, 60HZ

14.?Voltage(v)220-240, 360-400, 420-460, 630-690

Technical feature

A .Maual Continuously Variable Transmission

B. Frequency Cnverter adjust motor gear box

C.Fixed speed output transmission

Specifications

Design?and?Features

1. Horizontal?TUL, Vetrical?TUR

2. Bare-Shaft?Consturction

3. Hygienic?Design?of?the?attachement?of?the?rotors

4. Sanitary?Mechanical?Seal,?Easy?cleaning?and?maintenace

5. Applied?to?CIP?Cleaning?and?sic?Sterlization

6.?according?to?USA?3A?Standard

Applications

This?pump?is?deal?for?the?transfer?of?viscous?as?well?as?low-wiscous?media?in?the?food?processing,?cosmetics?and?pharmaceutical?Industries.

Principles

1. As the lobes rotates, the space on the suciton side increasese as one lobe is distanced from another, thus creating a partial vacuum which draws the fluid in to the pump chamber.
?

2. As they are rotated by the shafts,each lobe is consecutively filled and the fluid is displaced to the delivery side.The small gaps between the robes and between the lobes and the walls of the pump body ensure that the spaces are duly filled.
?

3. The pump housing is ompletely filled and the fluid escapes through the teeth of the lobes and is forced against the walls of the spaces. Which contributes to the pump aciton

Competitive?Advantage

“DONJOY is the only company that pass nine series of products by American 3A certification organization in Asian sanitary pumps and valves field.”
