lead-free medium reflow oven

lead-free medium reflow oven
Specifications : E8(8-Zone)
General
Outside Dimension(L*W*H) : 4800x1250x1490mm
Standard Color : Computer Grey
Weight : Approx.2250KG
Number Of Heating Zones : Up8/Bottom8
Length Of Heating Zones : 2900mm
Exhaust Volume : 10M3/minx2  Exhausts
Standard Feature Of Control System
Electric Supply Required : 3phase,380V 50/60Hz
Power For Warm Up 30KW
Power Consumption 8KW
Warming Time : Approx.20 minute
Temp. Setting Range : Room Temp. ---  300℃
Temperature Control Method : PID Close Loop Control + SSR Driving
Temperature Control Precision : ± 1.0℃
Temperature Deviation on PCB : ± 1.5℃  (by MR Board Test Standard)
Heating Element  : Especial Heating elements For Long Life ;
Commutated Element  : Aluminium Alloy Plate
Max. Temp. Gap Between Preheat & Reflow Setting  : 80℃
Max. Temp. Gap Between Preheat Zones Setting : 40℃
Max. Temp. Gap Between Reflow Zones Setting : 50℃
Data Storage : Process Data and Status Storage
Abnormal Alarm : Abnormal Temperature (Extra-high / Extra-low Temp.)
Board Dropped Alarm : Tower Light: Yellow–Warming; Green-Normal; Red-Abnormal
Features Of Conveyor System
Rail Number : 1 Lane
Max.Width Of PCB : 320mm (Option:610mm )
Components Clearance : Top/ Bottom Clearance of PCB is 25mm
Converyor Direction  : L→R (Option: R→L)
Fixed Rail Side : Front Rail Fixed(Option:Rear Rail Fixed)
Transmission Agent  : Air-Reflow =  Chain + Mesh ,    N2-Reflow=Chain(Mesh is option)
Center Support (Option) : Preventing PCB warp such too wide and heavy component load
Converyor Height : 90020mm
Converyor Speed Range : 300~2000mm/min
Lubrication Auto-Afflux : Standard
Temp. Thermocouple Slot   : Standard
Driven Top Hood Opening : Standard
On Line Editing  : Standard
Cooling Method : Forced-Air   (Standard), Water-Chiller (Option)
Model for Nitrogen Process
Power For Warm  : Up 32KW
Power Consumption : 12KW
Flux Management System : Flux Reclaimed and Filtration standard for N2Oven, easy clean-up.
N2 containment at Entry and Exit End Standard
Flux Reclaim System  : Standard
Nitrogen Flow Meter  : Standard
Oxygen Analyser : Option
Nitrogen Consumption [Standard] : 400~1000PPM 20M3/H
Water Chiller : 3 HP ;  External Stand-alone Type ;  Powerful Cooling suit to Lead-Free Process Required
