Home > Products > New product > PDS Series rectangular Electrical Plug Connector MIL-C-55302
PDS Series rectangular Electrical Plug Connector MIL-C-55302
- 10000 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
MIL-DTL-26482 I Series amp military pin connector VG95234 RoHS approved Series bayonet 4 pin connector
-
GJB598 II Series (MIL-DTL-26482 II Series) Circular Electric Plug Connector
-
MIL-DTL-38999I military circular connector gold plated connector pins
-
MIL-DTL-38999-II wall-type front-mounted Connector
-
MIL-DTL-38999-III high temperature connectors electronic D38999/26FG25SN Electric Plug Connector
-
MIL-DTL-38999-IV Electric Plug and socket Connector
Product Details
| Brand Name | hanglian | Place of Origin | China | |
| Model Number | PDS |
Product Description
Product Introduction
*The product conforms to GJB1438/1-1996.
*Hyperbolical sockets.
*Standard grid spacing of 2.54 mm.
*Designed by reference to MIL-C-55302.
*The termination types are PCB dip soldering, solder type and wire wrapping, etc.
*Anti-misinsertion identification guide pin and guide sleeve provide 6×6=36 identifications.
Main Technical Properties
[Mechanical properties]
--Diameter of contact: φ0.76mm
--Vibration: frequency: 10-2,000Hz, acceleration: 147 m/s2
--Shock: 980 m/s2
--Durability: 1,000 times
[Environmental properties]
--Ambient temperature: -65℃ to +125℃
--Relative humidity: 98% at 40±℃
[Electrical properties]
--Contact resistance: ≤0.01Ω
--Rated current: 3A
--Rated voltage: 250V
--Insulation resistance: ≥5,000MΩ at normal temperature, ≥1,000MΩ in hot and damp conditions
