Multi - Environment PM2.5 Monitor Module , CO2 / VOC / PM2.5 / PM10
- T/T L/C D/P D/A
- 7 days
You May Like
-
Heat Pump Thermostat ProgrammableAC Thermostat Multistage 24VAC
-
Multifunctional Multi Gas Detector And Wireless Transmission
-
Home Co2 Monitor Wall Mounted Carbon Dioxide Detector With LCD Display
-
Temperature Humidity Co2 Detector For Indoor Air Measuring And Controlling
-
3 In 1 And 3 Relays Co2 Controller Humidity And Temperature Sensor
-
NDIR CO2 Sensor / 2000 PPM Carbon Dioxide MeterFor Shopping Mall
Product Details
| Brand Name | NFCase | Place of Origin | China | |
| Model Number | AIA-1 |
Product Description
Certification:CE,FCC,MSDS
Specification
|
General Data |
|
|
Power supply |
DC5V?? |
|
Detection parameters |
PM2.5/PM10, CO2, VOC, air temperature & RH |
|
Output |
RS232-TTL level (Modbus) Optional: RS485 (Modbus RTU)/ WIFI? (Modbus TCP) |
|
Dimensions |
62mm(W)×94mm(H)×26mm(T) |
|
Housing materials |
Casting aluminum, surface treatment (industrial class design) |
|
Standard |
CE-Approval |
|
PM2.5/PM10 Date |
|
|
Sensor type |
Laser scattering |
|
Measuring range |
0~600μg∕? (scalable) |
|
Display resolution |
0.1μg∕? |
|
Accuracy |
5μg∕?±10% reading @25℃,10%~60%RH |
|
Temperature and Humidity Date |
|
|
Sensor type |
High precision digital integrated temperature and humidity sensor |
|
Measuring range |
0℃~50℃ / 5~95%RH (non-condensation) |
|
Resolution |
Temperature: 0.01℃??????????? Humidity: 0.01%RH |
|
Accuracy |
Temperature:<±0.5℃@25℃???? Humidity:<±3.0%RH (20%~80%RH) |
|
CO2 Date |
|
|
Sense type |
Non-Dispersive Infrared Detector (NDIR) |
|
Measuring range |
0～2,000ppm |
|
Display Resolution |
1ppm |
|
Accuracy |
±40ppm + 3% of reading |
|
TVOC Date |
|
|
Sensor type |
MEMS metal oxide sensor |
|
Measuring range |
0～4.0mg∕? (Scalable) |
|
Display resolution |
0.001mg∕? |
|
Accuracy |
±0.01mg+10%of reading |
Features
Structure Design: Industrial class design with reliable and trustworthy guarantee.
Measurement parameters: Integrated multi-sensors inside. You can choose different sensing according to your different applications.
Accuracy: Dependent on a number of our own patented technology, it’s not only completely designed in the digital accuracy with high resolution, but also designed to avoid the impact of the measured value by the environmental temperature and humidity.
Reliability: Full die-cast aluminum enclosure to ensure gas sealing and shielding, and also ensure no leakage of the laser, improve anti-jamming capability.
Assembly advantages: Supply up to six kinds of air interface options to meet more application demands.
Scalability: Reserved for multiple external interfaces, optional to be connected a particle cutter or a moisture removal tube etc.
Optional measurements: Offering a variety of models available, there must be a part of you.
Typical application
Air quality detectors
Automobile carriage air quality detection and control
Air purification equipments
Conditioning fresh air systems
Ventilation equipments
Other IAQ on-line monitors
Dimensions
Models guide
|
Model |
PM2.5 |
Temp/RH |
CO2 |
TVOC |
Output |
Application |
|
MSM-1501 |
● |
● |
RS232-TTL level (Modbus RTU) |
. Inside in an air purification equipment, air cleaner, fresh air equipment, IAQ detector/monitor |
||
|
MSM-1503 |
● |
● |
● |
|||
|
MSM-15 |
