Engraving CNC High Speed Spindle Drill Collet D1822 Westwind
Negotiable
/ Piece
1 Piece(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Router CNC Spindle High Precision Collet H912B ABL 120000 rpm
-
PCB Drilling Spindle Drill Collet for Hitachi machine H916C ABL
-
WESTWIND PCB drilling Router Collet for Hitachi machine H920B ABL
-
200000 rpm Westwind Air Bearings Drill Collet H920E1 ABL
-
ABL HR08A Spindle drill Collet PCB Air Bearing spindle collet 80000 rpm
-
High precision 4C Spindle Router Drill Collet M320-64C Westwind
Product Details
| Brand Name | KLKJ | Place of Origin | China | |
| Model Number | D1822 |
Product Description
Certification:ISO9001:2008
?Quick Detail:
?
| MODEL | Name? | OEM | Max Speed? | Application? | Machine |
| D1822 | Drill Collet | WESTWIND | 160,000 rpm | PCB drilling? | CNC |
?
Description:
?
D1822 ?Westwind Spindle Collet of PCB Air Bearing spindle
?
High precision collet for PCB drilling or router spindle. ?Its high speed up to 200K rpm, for ?CNC machine. ?
Runout, vibration, torque, etc controled very strictly to meet high precision hole drilling.
?
What?is collet?
Collet is?a key important?spare?part?of PCB spindle,?quality?control?is?very?strictly,?longer?use?life? is?your?priority?choice.
We offer a range of spare?collets, precision matched to nearly one hundred kinds of spindles in PCB industry . According to the different applications, there are collet for PCB Drilling Machine spindle, for PCB Routing Machine Spindle and the Auxiliary collet. Using KLKJ collets will enhance the performance of your spindle and extend their working life.
?
Specifications:
| Collet list and application spindle | ||
| Model | PN | Application other Spindle |
| D1331-17 | 17593;17809;20924 | D1201-02 ,06 ,19 , 20 ,21 ,33 ,34 |
| D1263-03 ,04 ,06 ,07 ,08 ,09 , | ||
| D1199-03 ,D1210 ,ABW110 | ||
| 1531-01 ,02 ,04 ,06 ,09 , | ||
| 1331-01 ,02 ,03 ,07 ,08 ,09 ,10 , 13? | ||
| D1331-17 ,19 ,20 ,21 ,24 ,27 ,28 ,38 | ||
| D1331-26 | 38431;34381 | D1404 ,D1502 ,D1686-01 ,02 ,03 ,04 |
| 1331-25 ,26 ,29 ,31 | ||
| D1331-36 | 38730 | D1331-36 |
| D1331-41 | 37462 | 1331-08,30,32,41,42,44,D1201?? |
| 1531-08 ,SM170 , MCT150 ,160 ,170 | ||
| D1331-47 | 41928 | 1331-22 ,1331-47 |
| D1331-49 | 41611 | 1331-49 ,48 ,51 |
| D1686 | 40374 | D1686-10 ,11 ,12 ,13 ,15 ,16 ,18 ,19 ,23 |
| D1722-03 | 1264 ,1600 , H501 ,H512 ,1600-01 ,H516D | |
| D1769 | 41611 | 1769-06 ,10 |
| D1787 | D1787-01 ,D1787-07 | |
| D1822-01 | D1822-09 | |
| M320-24 | 11257 ; 08085A1 | D1519-01 , M320-01 ,03 ,05 ,07 ,10 ,11 ,16 ,17 |
| M320-18, 19 , 20 ,22 ,23 ,27 ,28 ,29 ,30 ,36 ,47 ,52 | ||
| M320-38 | 16194 | 1303 , M320-43 , M320-38 ,M320-55 |
| M320-64 | 16703 | M320-46,50,62,63,64,65,66 |
| M320-63A , 64A ,65A , 66A ,D1170-04,D1303-01, | ||
| D1303-02,D1524-01,02,03,04,05 | ||
| M320-64C | 39773 | M320-64C |
| H242B | H242B | |
| HR08A | HR08A | |
| H912B | ABL-125 ,ASC125 , AW125 , 127480 ,88288 | |
| H916A3 | H916A3 , H916A | |
| H916C | 143480 | H916B |
| H920B | AW160-08 , AW160 , H920A | |
| H920E1 | H920E1 | |
| ABWR80 | 17508 ; 216844-10 , | 1251-03,ABWR80,M320-60,ABW80 |
| ABW125 | 41844;414741-01 | D1199-06,10,ABW125,ABW-170,D1473-07 |
| SC-53 | 53533;033503 | SC-53 |
| SC-63 | 63503 | SC-63 |
| SC-3163 | 263508 ; 263506; 263504 | SC-3263,HB60B,61B,HB60D,RA-60,KL-60B |
| W-6 |
