Perforated Steel Raised Floor Interchangeable Flexible Timely Delivery

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Tianchi		Place of Origin	China
Model Number	TC

Product Description

Delivery Time:5 working days after received your payment
Certification:SGS

Perforated Steel Raised Floor Interchangeable Flexible Timely Delivery
?

Material 1	Anti static HPL finish
Material 2	Steel
Anti-static property	1.0x106 ~ 1.0x 109ohms
Size	60060035 mm
Panel dimension	within ±0.25mm
Panel weight:	Approx 11KG
Type	FS800
Concentrated loading	363 kg
Ultmate loading	11250 N
Uniform loading	16500 N/SQM
Rolling loading	2950 N
Fire-proof perfprmance	Class A

?
?
Concentrated Load

Type (TianChi)	Size (MM)	Fire Proof	Concentrated Load			Ultimated Load (N)	Uniform Load(N/m2)	Impact Load(N)	RollingLoad(N)
Type (TianChi)	Size (MM)	Fire Proof	LB	N	KG	Ultimated Load (N)	Uniform Load(N/m2)	Impact Load(N)	10	10000
? TC450	? 60060030	? A	? ≥440	? ≥1960	? ≥200	? ≥5880	? ≥9720	? ≥295	? 1958	? 1566
? TC650	? 60060035 ?	? A	? ≥662	? ≥2950	? ≥301	? ≥8850	? ≥12500	? ≥445	? 2946	? 2356
? TC800	? 60060035 ?	? A	? ≥800	? ≥3550	? ≥363	? ≥11250	? ≥16100	? ≥536	? 3560	? 2670
? TC1000	? 60060035 ?	? A	? ≥1000	? ≥4450	? ≥453	? ≥13350	? ≥23000	? ≥670	? 4450	? 3560
? TC1250	? 60060035 ?	? A	? ≥1250	? ≥5560	? ≥567	? ≥16680	? ≥33000	? ≥780	? 5560	? 4450
? TC1500	? 60060035 ?	? A ?	? ≥1500	? ≥6660	? ≥680	? ≥26690	? ≥43000	? ≥780	? 6670	? 5560

Flat head pedestal	?
Steel flat head	757535mm
Steel pipe with screw	Diameter 18mm
Thickness of pipe	1.2mm
Bottom plate	95952mm

Stringer	?
Size	5703520mm
Thickness	1mm

?
Features:
1) Steel structure, high mechanical strength, high load capacity, shock resistant
2) Electrostatic spray processed surface
3) Water, fire, dust and corrosion proof
4) High pressure plywood for an easy-to-clean anti-static material
5) Accurately sized, interchangeable, flexible, convenient to install
6) Peripheries have straight edge or hem, no adhesive tape needed
?
?
Why us:
1. Wide range of product
2. Fine Workmanship
3. Lead R&D ability
4. Perfect Packing
5. Timely Delivery
?
?
