QTZ125 High Quality Construction And Building Tower Crane 180m

QTZ125 High quality Construction And Building Tower Crane 180m

1. Specification: TC6512-10

2. Dimensions: standard section 2,000mmX2,000mmX3,000mm

3. Material: All main chord?be made of ?Q345B steel

4. Parameter: Maximum hoisting capacity is 10 tons, the longest jib is 65m, maximum independent lifting height is 53m, maximum attached height is 180m.

5. Model: TC6512-10

Quick Detail:

1.?Mast standard section: 1,800mmX1,800mmX2,800mm?, 1835mmX1835mmX2500mm,

??? Plate standard section of 2,000mmX2,000mmX3,000mm.

2. The longest jib is 65m,the jib combination decreases progressively 5m each,?and the minimum arm length is 45m.??????????

3. The maximum hoisting capacity is 10 tons.

4. The maximum lifting capacity at a distance of 65m is 1.2ton.

5. The maximum hoisting moment is 156t.m.

6. The maximum independent height is 53m and the maximum attached height is 180m.

7. Hoisting mechanism: Adopting a double-speed winding motor?? 37KW .

8. Slew mechanism: Adopting a double gyration winding motor? 5.5 KWX2. Hoisting mechanism: Adopting a three-speed winding motor?? 5KW .

9. Tower crane foundation type: Embeded leg fixing type. Stone bolt fixing type

??Our main products are:

Hammer head tower crane??QTZ63(TC5013),QTZ80(TC5610,TC5610A,TC6010TC,TC6010A)QTZ100(TC6013-6,TC6013A-6,TC6013-8,TC6013A-8)QTZ125(TC6015-8,TC6015A-8,TC6512-10,TC6512A-10)QTZ160(TC7013-10,TC7013-12)QTZ250(TC7520-12,TC7520-16)

Flat head tower crane QTZ125(TCP6015-8,TCP6512-10)QTZ160(TCP7013-10,TCP7013-12)

TC6512-10(QTZ125)? Plated type standard?section which?can be exchanged?with POTAIN\' one.?

Table for main technical performance parameters for TC6512-10 tower crane:
