DPB-260 Alu Alu Blister Packing Machine With Servo Motor 26008001700mm

DPB-260 Alu Alu Blister Packing Machine With Servo Motor 2600×800×1700mm

Applying:

This machine is suitable for pharmacy, medical machinery, foodstuff, electric, hardware industry’s capsule, tablet, syringe, ampoule, medical apparatus, food, electric appliance,hardware etc blister package.this machine with paste feeder it is special?for granule?in food?industry which is in full compliance with GMP requirements.

Feature:

1) The machine body adopt guide track structure instead of housing window localization.
Moulds such as forming, heat seal, punch can be adjusted willingly on the guide track,
suitable for different size plates, easy adjust, good adaptability, high accuracy.
2) Mechanism hands for traction, stroke adjustable, easy operation, stable running.
3) With parallelaxes bevel gears reducer, avoid loosen or slippage caused by chain or belt.
4) Mould location by pin, easy change mould.
5) Frequency converter speed change, punch frequency 6—35 adjustable
6) Adjustable operation panel, suitable for different plates, easy operation.
7) Can equip with PLC, human-machine interface, high automization,photoelectronic
registration, localize heat seal, automatic error compensation.
8) Aluminum foil reel adopt stable device, cancelled the affection of pull force change with
the ALU foil reel gradually diminish, thus it made a great role in synchronization.
9) The up and low moulds for heat seal mate each other completely, with multi level cylinder
compressing heat sealing, the net pattern show clearly, firm, and reach 100% seal.
10) Low heating temperature of up and low heating with aluminum alloy, finally make out the
plump forming blister, specially suitable for packing of hot sensitivity medicines.

Parameters:

We can offer you different capacity blister packing machine

Product description:
