1000 mm Galzed Tile Roll Forming Machine Colorful Roofing Sheet Making Machine

FOB Price

USD $10500 - $18500/

1 (Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	MST		Place of Origin	China
Model Number	MST 25-210-840

Delivery Time:35 working days after received your payment
Certification:CE / SGS

1000 mm Galzed Tile Roll Forming Machine Colorful Roofing Sheet Making Machine

1. Description:

This shape of machine can produce two models of roof panel,one is the flat normal roofing,another is tile.

That means with press on the normal roof.Customers can make the production according to their orders.

2. Competitive Advantage:

Save money Save space Easy operate Change model freely

3. Flow?chart

4. Specification

NO.	ITEM	PARAMETER	NOTE
1.	Suitable? material	Type	Pre-painted?sheet, Galvanized?sheet Galvanized Aluminum
Width(mm)	1000mm
Thickness(mm)	0.3-0.8mm
Yield?stress(mm)	Q235
2.	Product? specifications	Detail?as?the?attached?file
Length	Any?length
3.	Power? requirement	Type	380v/3ph/50hz	Motor?brand?shanghai? Lichao
Main?Motor?power	4kw
Cutter?power	4kw
4.	Forming?speed(m/min)	2-10m/min	Not?include?the?time? of?cutting
5.	Manual?Decoiler (Optional)	Type	Manual
Max?capacity	5t
Suitable?coil?OD(MM)	1000
Suitable?coil ID(MM)	508
6.	Forming?stand	14	Depend?on?actual?design
7.	Thickness?of?structure	16mm
8.	Forming?shaft?diameter(mm)	70?solid
9.	Type?of?cutting	Roll?formed?and?length-set?cutting
10.	Control?system	Panasonic?PLC?and?inverter
11.	Install?dimension(depend?on?the?final?design)	7.3m×1.5m×1.2m	Without?panel?length
12.	Total?weight?(Approx)	3.5T	Depend?on?final?design

5. Applications:

?	Our machine	Other company \'s machine	Influence of the machine
Machine\'s base	High strength H350 / H400 steel. machine through milling macine after welding	H270 steel mark, after welding use manual polish	keep base in the same?horizontal line, ensure?product standard
Roller material	High grade No.45 forged steel, with digital-controlled procession, Plated with 5 um chrome coated	Normal No. 20 steel with ?Simple polished and have no coating	Roller will have longer?use life and ensure the?products have same size,no nick on the surface.
Side wall	Use high strength16mm thickness steel panel mark	Use 12 mm thickness steel panel mark	Ensure machine harder to?deform, keep the product?accurate and stable
