Roof Panel Corrugated Roll Forming Machine For Purlin 4Kw 10 m / min speed
US$ 8500 - 13000/
/ Set
1 Set(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Steel Profile Roofing Corrugated Sheet Roll Forming Machine 0.3 - 0.8mm Thickness
-
1000 mm Galzed Tile Roll Forming Machine Colorful Roofing Sheet Making Machine
-
Hydraulic Control Glazed Tile Roll Forming Machine For Construction Metal Making
-
Automatic Roofing Arc Tile Roll Forming Machine With Curve Cutting Device SGS
-
3 Phase Manual Glazed Tile Roll Forming Machine With Pillar Leading Pressing
-
Large Span Roofing Glazed Tile roll Forming Machine Metal Profile Steel 4kw 5t
Product Details
| Brand Name | MST | Place of Origin | China | |
| Model Number | MST18-76-836 |
Product Description
Certification:CE/SGS/ISO9001
Roof Panel Corrugated Roll Forming Machine For Purlin 4Kw 10 m / min speed
Description:
This?model?of?machine?is?widely?used?in?Africa?and?middle?east.The?feeding?width?is?1250mm,and?cover?
width?is?1060,it?is?perfectly?overlapped.Save?material?and?out?look?is?beautiful.
Flow chart
Standard Equipment of Machine:?
| Uncoiler | 1 set |
| Guiding Equipment | 1 set |
| Roll Forming Equipment ? | 1 set |
| Post Cut Equipment | 1 set |
| Hydraulic Station? | 1 ?pc |
| PLC Control? | 1 ?pc |
| Supporter Table | 2 ?pc |
?The Technical Parameters:?
| Suitable raw material | Color steel sheet; Galvanized steel sheet |
| Thickness of the material | 0.3m to 0.8mm |
| Yield strength of material | 235Mpa |
| Uncoiler\' s loading capacity | Max. Capacity: 5000Kgs. (can be increased to be 10 tons) |
| Forming speed | About 15-20m/min |
| Main motor power | 4Kw(Depend on final design) |
| Hydraulic station power | 4Kw(Depend on final design) |
| Controling System | Mitsubishi PLC & converter |
| Votage | 380V, 3 phase 60Hz or according to at buyer\' s requirment |
| Quantity of the roller group | At lest 12 groups(depend on final design) |
| Machine dimension | About 5.8m*1.3m*1.3m(depend on final design) |
| Total weight | About 4000kgs(depend on final design) |
Competitive?Advantage:
1.?save?space
2.?easy?installation
3.?perfect?service
4.?excellent?quality
5.?Operate?easily
Machine picture
