Home > Products > Tower Crane > QTZ50,40tower crane
QTZ50,40tower crane
Negotiable
/ Unit
1 Unit(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | Hengsheng | Place of Origin | China | |
| Model Number | QTZ5010,5008,4810,4708,4208 |
Product Description
|
|||||||||||||
|
Model parameters Performance |
QTZ5010 | QTZ5008 | QTZ4810 | QTZ4708 | QTZ4208 | ||||||||
| Maximum rated torque(KN·m) | 500 | 500 | 500 | 400 | 400 | ||||||||
| Maximum lifting load(t) | 4 | 4 | 4 | 4 | 4 | ||||||||
| Maximum working amplitude(m) | 50,48,48,46.8,42 | ||||||||||||
| Hoisting height (m) | Independent | 29 | 29 | 29 | 29 | 29 | |||||||
| Adhered | 120 | 120 | 120 | 120 | 120 | ||||||||
| Lifting capacity at jib tip(t) |
|
||||||||||||
| Hoisting speed (m/min) | a=2 |
|
|||||||||||
| a=4 | |||||||||||||
| Radius changing speed(m/min) | 22/33 | 22/33 | 22/33 | 22/33 | 22/33 | ||||||||
| Swiveling speed(r/min) | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | ||||||||
| Climbing speed(m/min) | 0.4 | 0.4 | 0.4 | 0.4 | 0.4 | ||||||||
| Dead load(t) | 36/22.5,42.7/21.5 | ||||||||||||
| Upper chord of lifting beam | φ89×4.5 | ||||||||||||
| Standard section dimensions(mm) |
|
||||||||||||
| Matching motor | Winding motor, transform, speed regulation, smooth operation | ||||||||||||
| Materials of lifting mast | ∠140×12 Q235B ∠160×12 Q235B square pipe∠75×6 | ||||||||||||
| Parallel height of lifting beam(mm) | 1040 | ||||||||||||
Besides this kind of crane. We also have many other kind of crane such as Tc series, HSTseries. And of our cranes, the maximum lifting capacity can be 25t, and the maximum operating radius can be 70m.The maximum lifting capacity at ti end can be 5.2t. The maximum height can be 280m.Also our tower can be customized according to your requirement
