Labor Saving Soil Block High Speed Rotary Tablet Press 500 Ton With Mitsubishi PLC

Labor Saving Soil Block High Speed?Rotary Tablet Press 500 Ton With Mitsubishi PLC

1. Description:

The licking block of raising livestock salt takes salt as carrier, is produced by suppressing with the pressure 150Mpa/m2 the various trace elements in mineral substance, which is needed by domestic animals. After domestic animals freely lick the block, it obtains the comprehensive trace elements in mineral substance every day, and the routine feeding cannot provide such trace elements. The licking block is high dense, hard like stone, and can adapt to various extreme climates, and it can stand wind blowing, exposure to sun, and rain showering. The licking block is too tough to be gnawed by domestic animals, so the licking amount is possible to be under control effectively, both guarantees the daily needed ingestion quantity for mineral trace elements and does not have the waste, there is no need for manual control, so truly realizes food licking freely, and cultivating persons do not have to hold specialty knowledge to apply freely and obtain enormous benefit.

SYST-500 10kg mineral salt briquette machine designed specially for compressing animal salt licking blocks, animal feeding nutritional blocks, salt briquettes and so on. Combined with many years of Research,Design,and production experience. This kind of hydraulic tablet press machine continued our former manufactured model essence,aimed at salt lick pressing forming feature. High pressure, very good stability for long-time high pressure.The mould of hydraulic tablet press machine replaced very easy,operation automatically with a high degree. No need to add material into the middle mould by manual. This tablet press machine have hopper, just need to put the material into the hopper, then the pusher will feeding the material into middle mould automatically and compressed itself. PLC controls every tablet that pressing and be formed out movement very precisely. Compressed automatically and continuously.

The moulds can be replaced randomly according to customer’s requirement, disassemble more conveniently. Also can according to different material properties to choose different material moulds, to achieve different usage effects.

Our hydraulic tablet press machine can equip Automatic screw conveyor machine, mixer and other auxiliary equipment for continuous production, it can improve production automation, and also save the labours. Realized to liberate people from production line.

Delicate appearance design, Instead of large size, clumsy appearance, difficult installation for conventional hydraulic machine. Compared with same tonnage hydraulic press, our hydraulic tablet press machine size is more smaller, so it can save production space in the process of operation. Our tablet press machine oil system design adopts Taiwan professional hydraulic system technology. No oil leakage, fast speed, Improved equipment performance and reducing the power consumption, save the space, Truly technical services in line with international standards.

2. Quick Detail:

3. Description:

> The whole machine is made of stainless steel,which can prevent from polutions

> All electrical parts adopt famous brand, such as:omron, schneider, etc.,

> Control part adopts \"Canadian TouchWin PLC\" programming

> operation system have manual mode and automatic mode

> all machines adopt Taiwan imported hydraulic components

> the pressure can be adjusted according to your requirement randomly

> all key position adopts mechanical and electrical dural control

4. Applications:?

a . Chemical: disinfection tablets,detergent tablet, Chlorine tablet, camphor balls, glass tablet, ceramic tablet, magnetic tablets and so on.

b . Food: candy tablet, seasonings tablet, Chicken tablets, coffee tablet, chocolate tablet and etc.

c . Agriculture: animal feeding blocks, fertilizer tablets, livestock salt licking blocks, seeding nutrition soil tablet.

d . Health Products: calcium
