Home > Products > Silent Diesel Generator Set > 50kw / 63kva Prime Power Cummins Engine Slient Diesel Generator Set
50kw / 63kva Prime Power Cummins Engine Slient Diesel Generator Set
US$ 4 - 5
/ Set
1 Set(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Water - Cooled In - Line Perkins Diesel Generator Set Six Cylinder 100-200kw 225kva
-
500-1100 Kw/ Kva Canopy Industrial Diesel Generators With 720 L Fuel Tank Capacity
-
IP23 Three Phase Silent Diesel Generator Set 600kw / 750kva For Company
-
375Kva Three Phase Silent Diesel Generator Set With Water Cooling System
-
Prime Power 60kw / 75kva Cummins Engine soundproof slient Diesel Generator Set
-
Meccalte Alternator Synchronous Industrial Genset 16.9:1 Compression Ratio
Product Details
| Brand Name | NFCase | Place of Origin | China | |
| Model Number | AIA-1 |
Product Description
Certification:CE,FCC,MSDS
Technical Specifications :?
|
Genset |
Prime Power (kw/kva) |
50 / 63 |
|
Standby Power (kw/kva) |
55 / 69 |
|
|
Voltage Recovery Time |
≤1S |
|
|
Rated Current (A) |
90 |
|
|
Rated Frequency (Hz) |
50 |
|
|
Frequency Recovery Time |
≤5S |
|
|
Running Noise db(A)/7m(Silent type) |
75 |
|
|
Battery capacity (V-Ah) |
12V 100Ah |
|
|
Fuel Tank Capacity(L) |
100 |
|
|
Engine |
Engine brand |
Cummins |
|
Output Power (kw) |
50 |
|
|
Cylinder No. & Config. |
4, in-line |
|
|
Combustion System |
direct injection |
|
|
Compression Ratio |
16.5:1 |
|
|
Displacement (L) |
3.9 |
|
|
Bore X Stroke (mm) |
102*120 |
|
|
Engine Speed (r/min) |
1500 |
|
|
Speed Governing |
Mechanical |
|
|
Starting System |
24V DC Electric |
|
|
Filter System |
Dry oil filter/Fuel filter/Oil filter |
|
|
Cooling system |
Water-cooled |
|
|
Alternator |
Alternator brand |
Stamford, Mecc-alte,Faraday… |
|
Excitation System |
Brushless, self-exciting |
|
|
Voltage Regulation Mode |
AVR |
|
|
Connection Type |
3phase,4wires,”Y” connection |
|
|
Pole No. |
4 |
|
|
Rotation Speed (r/min) |
1500 |
|
|
Temperature Rise (℃) |
125 |
|
|
Insulation class |
H |
|
|
Voltage Regulation (0 load) |
≥95%～105% |
|
|
Protection Grade |
IP23 |
Our Picture :
Generator?soundproof/Silent?and?canopy
Excellent?ventilation Black?finish?stainless?steel?locks?and?hinges Zinc?plated?or?stainless?steel?fasteners Body?made?from?steel?components?treated?with?polyester?powder?coating Two?large?doors?on?either?side Radiator?fill?access?plate Fully?guarded?cooling?fan?and?battery?charging?alternator Fuel?fill?and?battery?access?via?lockable?access?doors Emergency?stop?button?on?canopy?exterior Lube?oil?drain?and?radiator?drain?to?exterior Control?panel?viewing?window Lifting?points?on?base?frame??Our?Service:
?If?you?are?interested?in?our?products?we?sincerely?invite?you?to?take?a?visit?of?our?factory?when?you?are?in?China.?We?can?drive?to?pick?you?up?and?visit?our?factory. Suggest?the?best?choice?or?referential?suggestion?based?on?customers’?information.?Answer?all?questions?about?the?product?from?customer. Build?customers’?profiles,?follow-up?service,?make?regular?calls?on?customers.Warranty?and?Maintenance:
Guarantee?Period:?One?year?or?1000?running?hours?whichever?comes?first.? During?the?guarantee?period,?the?spare-parts?will?be?sent?through?your?shipping?agency?in?China.? Spare-parts?can?also?be?sent?by?air?express. 24?hours?service?hotline?is?avContact Us
