Home > Products > Cat5e SFTP Cable > Industrial Network Cable Cat5e SFTP Cable UTP FTP SFTP PVC Jacket
Industrial Network Cable Cat5e SFTP Cable UTP FTP SFTP PVC Jacket
Negotiable
/ Meter
1 Meter(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
PULI Lan Cat5e Copper Cable SFTP 550Mhz Network 100 Base-T4
-
Solid Standard Cat5e SFTP Cable 4P Indoor Network Cable Bare Copper
-
Ethernet Network Cat6 SFTP Cable Copper Pass Fluke 305 m/roll
-
1000FT Cable SFTPCat 6 Ethernet Cat 6 Cable 500 Mhz Networking Cable
-
Indoor / Outdoor PULI Cat6 SFTP Cable Cat6 Coaxial Cable 305m 112 Braid
-
Energy Saving Ethernet Cat6 SFTP Cable PVC / LSZH Low Insertion
Product Details
| Brand Name | WONTERM | Place of Origin | China | |
| Model Number | WT5803-SF |
Product Description
Certification:CE/FCC/UL/ROHS
Industrial Network Cable Cat5e SFTP Cable UTP FTP SFTP PVC Jacket
Conductor:
Material: Bare copper
Number of pairs: 4 pairs
AWG: 24awg
Conductor diameter: 0.515±0.003mm
Material: Bare copper
Number of pairs: 4 pairs
AWG: 24awg
Conductor diameter: 0.515±0.003mm
Insulation:
Material: HDPE and FRPE
Diameter: 1.02±0.005mm
Average thickness: 0.212mm
Minimum point thickness: 0.2095mm
First screen: aluminum mylar shield (superposition rate: 25%)
Overall screen: 80/0.1mm TC braid shield (coverage: 60%)
braiding shield(48/64/96/112x0.12mm or 0.15mm or 0.16mm, braid material, AL-MG, CCA, CCS, copper or tinned copper for braid), FR/PVC or LSOH jacket
Sheath:
Material: PVC or LSOH
Nominal diameter: 6.0 ±0.2mm
Average thickness: 0.55mm
Minimum point thickness: 0.50mm
Operating temperature: -20 to 75°C
Minimum bend radius (install): (8*OD)
Flame test: CMX, CM, and IEC60332-1
Reference standard: TIA/EIA568B and IEC/ISO11801
Applications:
1. Used in the most of home applicances,computer,PCB,LCD,TV
2. The connectors could be JST,MOLEX,JAE or others suppliers as the require of customers.
Competitive Advantage:
1. All kinds of products passed RoHS FCC CE UL?certification
2. We are glad to make samples according to your drawings or specifications.
3. Inspections:100% tested before delivery
4. The products are all environmental safe products,no smell and non-fading.
