Two Channel Encoder Servo Motor Drives 220VAC for CNC Milling / Lathe Machine
Negotiable
/ Piece
1 Piece(Min.Order)
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Variable Frequency 50W AC / DC CNC Servo Motor For Automated Production Lines
-
High Precision Micro CNC Servo Motor 2500RPM 220V Synchronous Motor
-
Vertical CNC Machine Controllers 2 Axis Retrofit Lathe Machinery Numerical Control
-
2 Stage Planetary Reduction Gearbox High Precision With Tiny Backlash 10 Min - Arc
-
SZGH 45KW 380V AC Spindle Servo Drive 3 Phase with GSM / GPRS modules
-
4 Axis Lathe Machine Controller With PLC Programming / DSP CNC controller
Product Details
| Brand Name | SZGH | Place of Origin | China | |
| Model Number | SZGH-302 |
Product Description
Certification:CE , ISO
Two Channel Encoder Servo Motor Drives 220VAC for CNC Milling / Lathe Machine
SZGH-302 AC servo driver is high performance product, it realized in one driver to control two motors simultaneously, change the previous condition that one driver only connect one motor, now the SZGH-302 can work with double servo motor, one is for X axis servo motor, another is for Z axis servo motor simultaneously work, to a certain extent, it save our clients' application cost.
Specifications
?Mode of control: position, velocity and JOG control
??? Mode of input: pulse signal or analog voltage(0~±10V)
??? Frequency of pulse: 500KHz
??? Electronic gear: 1/30000~30000
??? Precision of control: ±0.01%
??? Mode of input: pulse signal or analog voltage(0~±10V)
??? Frequency of pulse: 500KHz
??? Electronic gear: 1/30000~30000
??? Precision of control: ±0.01%
work condition:
??? Input Power: single-phase or three-phase : AC220V (+10%,-15%)
????frequency: 50Hz±1Hz
??? Runing Temperature: 0~55°C, relative humidity: 40-80%
??? Storing or Transporting Temperature: -10~70°C
????frequency: 50Hz±1Hz
??? Runing Temperature: 0~55°C, relative humidity: 40-80%
??? Storing or Transporting Temperature: -10~70°C
????relative humidity: <=90%
??? Vibration: <0.5G, 10~60Hz?
??? Atmosphere pressure: 86-106kpa
??? Vibration: <0.5G, 10~60Hz?
??? Atmosphere pressure: 86-106kpa
?? No excessive flour dust,acid,alkali caustic gas and explosive gas,no strong electromagnetic interference
?? Direction of installation:servo drive’s installation direction must be upright
?? The ambient should be well ventilated
?? Direction of installation:servo drive’s installation direction must be upright
?? The ambient should be well ventilated
| Driver Model | Control Mode | Rated Voltage (A) | Current? (A)?? | Encoder Type | Matched? Motor | ||
| Torque | Position | Velocity | |||||
| SZGH-201 | √ | √ | √ | Single or 3phase 220VAC | 20 | Increment | 50-1.0KW |
| SZGH-301 | √ | √ | √ | Single or 3phase 220VAC | 30 | Increment | 750W-2.3KW |
| SZGH-302(two connect channel) | - | √ | - | Single or 3phase 220VAC | 30 | Increment | 750W-2.3KW |
| SZGH-501 | √ | √ | √ | Single or 3phase 220VAC | 50 | Increment | 2.3KW-3.8KW |
| SZGH-751 | √ | √ | √ | Single or 3phase 220VAC | 75 | Increment | 3.8KW-5.5KW |
| SZGH-503 | √ | √ | √ | 3phaes 380VAC | 50 | Increment | 3.8KW-5.5KW |
| SZGH-753 | √ | √ | √ | 3phase 380VAC | 75 | Increment | 7.5KW-11KW |
| SZGH-201H | √ | √ | √ | Single or 3phase 220VAC | 30 | Absolute | 50-1.0KW |
| SZGH-301H | √ | √ | √ | Single or 3phase 220VAC | 30 | Absolute | 200W-2.3KW |
| SZGH-501H | √ | √ | √ | Single or 3phase 220VAC | 50 | Absolute | 2.3KW-3.8KW |
| SZGH-503H | √ | √ | √ | 3phase 380VAC | 50 | Absolute | 3.8KW-5.5KW |
| SZGH-753H | √ | √ | √ | 3phase 380VAC | 75 | Absolute | 7.5KW-11KW |
We can Support Total CNC Control Solution!!!
