SC 96 Cavity Hot Runner Valve Gate PET Preform Mould

1. Application: all kinds of food bottles, washing bottles,fruit juice bottles, cup,glass bowl, milk bottle, ordinary bottle, Beverage bottle,etc.
2. Materials:PP, PET ,etc.
3. Customize Design is available, for instance,Engraved LOGO, AD.
Providing production of caps and related accessories,such as handle
4. Mould materials: P20, H13, S136,2316 and so on
5. Heat Treatment Hardness: HRC50 - 60
6. Mold cavity is replaceable,which is convenient to change the label
7. Number of cavities : Multi-Cavity
8. Operating Life: At least 5 million times life-time guaranteed
9.Customer service: Supply accesseries free within one year, provide technical support lifetime.


Adopt advanced technique to make each cavity self-lock,and ensure mold concentricity(tolerance less than 0.003mm).
The materials of core and cavity are made of mirror corrosion resistance plastic mold steel imported from Sweden and Germany.
International standard screw neck, imported nitrided steel with high hardness and long life time.
Advanced hot runner system with point to point control system,ensure uniform heating,which brings high-quality preforms.
Exceptional cooling system brings high efficiency.
Valves gate strcuture without manual cut tail,reduce the labor force.
At least5 million shots life-time guarantee.
Payment Terms: TT LC
