Three Cores with Stranded Alumininum Conductors XLPE Insulated Power Cable

Place of Origin	China

Hangzhou Dongxing Telecommunication Material Co.,Ltd is one of the professional China three cores with stranded alumininum conductors xlpe insulated power cable manufacturers and suppliers,Website: , and equipped with a productive three cores with stranded alumininum conductors xlpe insulated power cable factory and company, welcome to contact us.Basic InfoModel NO.: YJLV, YJLV22, YJLV32, YJLV42Voltage: Low and Medium Voltage CableInsulation Material: XLPEMaterial Shape: Round WireCertification: ISO, CCC, CE, RoHSBrand: DXDelivery Time: Within 10-15 WorkdaysPackage: Wooden DrumOrigin: Henan, China (Mainland)Application: ConstructionCurrent: DC & ACSheath Material: PVCWire Core Material: AlumininumModel: Yjlv,Yjlv22,Yjlv32,Yjlv42Product Name: Product NameTrademark:DXSpecification: alumininumHS Code: 760720000Product DescriptionApplication of?three core 600/1000V cables with stranded copper conductorsThese power and control cables are used for electricity supply in low voltage installation system. They are well adapted to underground use in industrial applications where chemical and mechanical protections are needed (refinery areas, chemical plant...).?Construction?of?three core 600/1000V cables with stranded copper conductorsConductor Solid Aluminum conductor, round stranded or shaped, Class 2 to BS 6460, IEC 60228.?Insulation PVC(Polyvinyl Chloride) type TI1Colour Code: 1 Core : Brown?? ? ? ? ? ? ? ? ? ? ? 2 Cores: Brown or Blue? ? ? ? ? ? ? ? ? ? ? 3 Cores: Brown, Black, Grey? ? ? ? ? ? ? ? ? ? ? 4 Cores: Blue, Brown, Black, Grey? ? ? ? ? ? ? ? ? ? ? 5 Cores: Green-yellow, Blue, Brown, Black, Grey,Above? ? ? ? ? ? ? ? ? ? ? 6 Cores: White Cores with black numbers?Filler(optional) PVC or Polypropylene yarnBinder Tape(optional) Polyester (Mylar) tapeInner Sheath/ Bedding PVC (Polyvinyl Chloride)?Armour Single Core: AWA (Aluminum WireArmour)??????????? ? ? ? ? ? ? Multi Core: SWA (Steel Wire or Tape Armour)Outer Sheath PVC(Polyvinyl Chloride), type TM1?Technical Information?of?three core 600/1000V cables with stranded Aluminum?conductorsVoltage rating 600/1000V?Temperature rating -20°C to +60°C?Bending radius Single core: 10 x overall diameter?? ? ? ? ? ? ? ? ? ? ? ? ?Multicores: 8 x overall diameterFlame retardant IEC60332 part 1, BS4066 part 1?Other product :1. PVC Insulated Power Cable2. 1~35kV XLPE Insulated Power Cable3. Aerial Insulated Cable4. Aerial Bundle Cable ( abc cable )5. Control Cable6. Bare Overhead Conductor (AAC/AAAC/ACSR)7. Non-sheathed PVC Insulated Cable (The highest rated voltage is 450/750V)8. Sheathed PVC Insulated Cable (The highest rated voltage is 450/750V)9. XLPE Insulated Cable for Coal Mine Application10. Underground Wire for Agricultural Applicationwe can manufacture one to five cores all kinds of VV cable.?China TypeDescriptionApplicationCuAlYJVYJLVXLPE insulation PVC sheath power cable (Cu/XLPE/PVC)To be laid indoors, in tunnel, cable furrow or pipe, the cable couldn't bear mechanical force outside?YJYYJLYXLPE insulation PE sheath power cable (Cu/XLPE/PE)YJV22YJLV22?XLPE insulation, steel tape armor,? PVC sheath power cable(Cu/XLPE/PVC/STA/PVC)To be laid underground, the cable could bear certain mechanical force, but it couldn't bear great pulling force.YJV23YJLV23XLPE insulation, steel tape armor,? PE sheath power cable(Cu/XLPE/PVC/STA/PE)YJV62YJLV62XLPE insulation,? no? magnetism steel tape armor,? PE sheath power cableYJV32YJLV32XLPE insulation, thin steel-wire? armor,? PVC sheath power cable(Cu/XLPE/PVC/SWA/PVC)Be applicable to the well, water inside and fall in the bad soil, the cable cans bear the equal dint outside the machine with pull the dint.YJV72YJLV72XLPE insulation, have no the magnetism thick steel-wire? armor,? PVC sheath power cableYJV42YJLV42XLPE insulation, thick steel-wire? armor,? PVC sheath power cableBe applicable to the well, underwater with the bottom of sea, the cable cans bear the bigger pressure with lead to pull the dint.
