Home > Products > Aluminium Channel Extrusion > Temper T5 T6 Aluminium Channel Extrusion For Electric Rails Series Inside Curtain Pole
Temper T5 T6 Aluminium Channel Extrusion For Electric Rails Series Inside Curtain Pole
Negotiable
/ Set
1 Set(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
6000 Series Aluminium Alloy Outdoor Curtain Rods , Extruded Aluminium Tube Electric Rails Series
-
White Extruded Aluminum Rails Shower Curtain Poles , Aluminium Extruded Sections
-
Customized T5 Aluminium Extrusion Profiles For Soft Sheer Blind White Color
-
Aluminium Extrusion Profiles With 6063 T5 Aluminium Sand Ivory Color EN755
-
Red Brushed Aluminium Extrusion Profiles With 6063 T5 Temper Material GB5237 EN755
-
Sapphire Brushed Extrusion Aluminum Profiles For Home / Hotel Window Curtain Blinds
Product Details
| Brand Name | Guo Hui | Place of Origin | China | |
| Model Number | GH8062 |
Product Description
Certification:ISO9001, ISO14001
1. Description:
1) aluminium round tube, electric rails?series of Jialisi curtain?for?home, hotel, office building etc
| item | extruded aluminium tube, electric rails series of Jialisi curtain for sun protection |
| Material | 6063 series Aluminium |
| Temper | T5 or customized |
| Size / Thickness | General profiles thickness from 0.6 to 2mm, length from 1m-6m or customized available; powder coating from 40 ~ 120 um. |
| Shape | customized |
| Application | Jialisi curtain for home, hotel, office building etc |
| Surface treatment | powder coating, wood grain , anodized, polish, brush finish and so on |
| Colors | Ref silver anodized or customized color available |
| Deep process | CNC, drilling, milling, cutting, welding, bending, assembling |
| MOQ | 500kgs for each item |
| Packing Details |
(1)Inside : packed with plastic protective film to protect each piece outside: Wrap to be bundles by waterproof craft paper, or by carton box (2)or customized packing as per customer’ instruction. |
| Delivery time | (1)die developing and sample testing: about 2 weeks. |
| (2) mass Production completed: 20-30days after sample is confirmed by Buyer. | |
| FOB Port | SHENZHEN / GUANGZHOU / FOSHAN |
| payment terms | T/T 30% for deposit, balance before shipping. |
| settlement term | Charge by USD/PCS, USD/M, or USD/KGS |
| production capacity | 2500 tons monthly, 30,000 tons annually. |
| Certificate and Standard | ISO9001, ISO14001 |
| Guarantee | Surface color can be stable for 10~20 years indoor using. |
2)?Primary Technical Data
A) Chemical composition
| Alloy | Si | Mg | Fe | Cu | Mn | Zn | Cr | Ti |
| 6063 | 0.2~0.6 | 0.45~0.90 | <0.35 | <0.10 | <0.10 | <0.10 | <0.10 | <0.10 |
B) Mechanical property
| Alloy | Temper | Tensile strength | Yield strength | Elongation |
| 6063 | T5 | ≥ 160Mpa | ≥ 110Mpa | ≥ 8% |
2. ? Key features
Simple and easy installation
suitable for construction and industrial material
high corrosion resistance
high weather resistance
good wear resistance.
3. why choose us?
(1) Wide range of surface finishes. Besides normal color eg white, bronze, champagne, black, special color is available to offer, eg similar steel, brush red, brushed sapphire and etc.
(2) The best suitable aluminium profiles series could be recommended as per customers’ need for curtain or sunblind
(3) on time delivery time
(4) Design flexibility
(5) or customized made (OEM) as per customers’ drawings or samples.
(6) Cost effective
(7) Low tooling costs and reasonable price of aluminium extrusion
(8) Rapid counter drawings and samples lead time
