Stainless Steel Camlock Fittings (Cam and Groove Quick Coupling)-Type DP

Stainless steel camlock coupling

1.SS camlock couplings, cam lock couplings, camlock fittings, quick camlock coupling,quick cam and groove connector ,quick camlock and groove fittings.

2.Stainless steel camlock fittings also used with salt water, water waste and many chemicals & can also be used with hydraulic oil and coolants.

3.Quick coupling features: Excellent corrosive resistance;high temperature ability; Long life expectancy;Wide working temperature.

High quality stainless steel camlock couplings Working pressure: 3/4"-2" 250PSI(17.6bar),

                  3"-4" 200PSI(14.8bar),

                  21/2" 225PSI(15.8bar),

                  6" 150PSI(10.5bar)

stainless steel 304 316 camlock couplings Temperature range: -150F to +500F

4. Camlock Quick Connector Material: stainless steel 316, stainless steel 304

Sizes: 1/2" to 8"

Spce: A B C D E F DC DP FC FA

Thread: NPT, BSPP, BSPT

SS camlock coupling workmanship: precision casting or forged

Pins, Rings and Safety clip material: Carbon steel plated or stainless steel

Handle material: Brass or stainless steel

Seal: NBR, BUNA, EPDM, VITON

 groove coupling standard: A-A-59326 (previously called MIL-C-27487) or DIN 2828

5.We aslo sell hose couplings ( Camlock, Sotrz, Bauer Guillenmin couplings ), stainless pipe fittings, valves, flanges, sanitary fittings and valves and so on.

6. Packing of hot sale stainless steel Self-locking Couplers camlock coupling:polybag inside, cartons outside,or according to customers requirements

   Groove quick couplings Delivery time:30days on we signed order.

7. Terms of payment: T/T, L/C,30% deposit.  Delivery Port: FOB Qingdao.
