12/13 rows Color Steel Sheet Roof Panel Color Steel Sheet Roll Forming Machine
- T/T L/C D/P D/A
- 7 days
You May Like
-
Cr12 Color steel plate Double Deck Forming Machine with PLC control
-
1250mm Tile and Roof Double Layer Roll Forming Machines
-
Color Steel Plate Roof Double Layer Roll Forming Machine With PLC Control
-
45# Steel Wall Panel Double Layer Roll Forming Machine With 10 / 11 Rows
-
Cr12 Plate Double Layer Roll Forming Machine For Roof Panel 0.3mm - 0.6mm 20m/min
-
Roof / Wall Sheet Metal Roll Forming Machines 380V 50Hz 3 Phases
Product Details
| Brand Name | HC | Place of Origin | China | |
| Model Number | HC19/30 |
Product Description
Certification:ISO
?Color Steel Sheet Roll Forming Machine
Quick Detail:
1. Suitable to process: Color steel plate
2. Width of the plate: 1250mm
3. Rollers: 12/13 rows
4. Dimensions: 7.7*1.55*1.91m
5. Power: 4+4kw
6. Rolling material: high grade 45# steel(plated chrome on surface)
7. Thickness of the plate:0.3-0.6mm
8. Voltage: 380V 50Hz 3phases
9. Material of the cutting plate: Cr12
10. Hydraulic: 40#
11. Processing precision: Within 1.00mm
12. Control system: PLC control
Description:
Double layer roll forming machine Main parameter
|
No. |
?Main parameter of Double layer roll forming machine |
|
|
1 |
Suitable to process |
Color steel plate |
|
2 |
Width of the plate |
1250mm |
|
3 |
Rollers |
upper level :12 rows Down level :13 rows |
|
4 |
Dimensions |
7700*1550*1910mm |
|
5 |
Power |
4+4kw |
|
6 |
Rolling material |
high grade 45# steel(plated chrome on surface) |
|
6 |
Thickness of the plate |
0.3-0.6mm |
|
7 |
Productivity |
20m/min |
|
8 |
Diameter of the roller |
Φ70mm |
|
9 |
Voltage |
380V 50Hz 3phases |
|
10 |
Material of the cutting plate |
Cr12 |
|
11 |
Hydraulic |
40# |
|
12 |
Processing precision |
Within 1.00mm |
|
13 |
Control system |
PLC control |
Equipment?components:?Man-made?uncoiler-roll?forming?machine-computer?control?system-hydraulic control system- cutting
Application
This kind of machine make two types of tile together perfectly, it has reasonable structure, beautiful appearance, with advantage of saving space, easy operate and especially welcomed by the customer? with limit area or site
Competitive Advantage
1. Pretty appearance
2. Various special model
3. mature foreign trade team
4. professional designing team
5. Lifetime maintenance
