Home > Products > Threading Tool Holder > MAS BT40 Threading Tool Holder 3m Runout Two Sides Contacting
MAS BT40 Threading Tool Holder 3m Runout Two Sides Contacting
Negotiable
/ Set
1 Set(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Precision Threading Tool Holder M12 Clamp Screw Hole MAS BT40 Standard
-
ANSI B5.50 Screw In CAT40 Tool Holder With 3m At 4X D And L 90 mm
-
Small Clamping Threading Tool Holder High Stability , HSK63A Tool Holders
-
ER32 BT50 Tool Holder Clamp Nuts And ER Collets For CNC Machining
-
Sintered Tungsten Steel Rod Straight Screw Bolt For Holding Cutter Head
-
Steped Shank Tungsten Carbide Welding Rods , Solid Carbide Rods
Product Details
| Brand Name | HIPPSC | Place of Origin | China | |
| Model Number | BT40-M06-50 |
Product Description
Certification:ISO9001
MAS BT40 Threading Tool Holder 3μm Runout Two Sides Contacting
?
?
Ⅰ?. Features
?
Ⅱ. Technical?Parametes??
?
|
Product?Name |
Threading Tool?Holder |
|
Spindle?Type |
MAS BT40 |
|
Screw hole size |
M6 |
|
Beat accuracy |
<0.003mm |
|
Processing?Type |
Endmilling, Reaming, Drilling, Finishing |
|
Product?Material |
Special?steel |
|
Hardness |
HRC58~60° |
Ⅲ. Product Show
?
?
Diagram
Available Standard Items
| Model?No. | L1 | L2 | D1 | d | M | α |
| BT40-M08-60 | 60 | 12 | 12.8 | 8.5 | M08 | 7° |
| BT40-M08H-60 | 60 | 12 | 15.4 | 8.5 | M08 | 7° |
| BT40-M08-90 | 90 | 12 | 12.8 | 8.5 | M08 | 7° |
| BT40-M08H-90 | 90 | 12 | 15.4 | 8.5 | M08 | 7° |
| BT40-M08-110 | 110 | 12 | 12.8 | 8.5 | M08 | 7° |
| BT40-M08H-110 | 110 | 12 | 15.4 | 8.5 | M08 | 7° |
| BT40-M08-135 | 135 | 12 | 12.8 | 8.5 | M08 | 7° |
| BT40-M08H-135 | 135 | 12 | 15.4 | 8.5 | M08 | 7° |
| BT40-M10S-60 | 60 | 12 | 15.4 | 10.5 | M10 | 7° |
| BT40-M10-60 | 60 | 12 | 17.8 | 10.5 | M10 | 7° |
| BT40-M10S-90 | 90 | 12 | 15.4 | 10.5 | M10 | 7° |
| BT40-M10-90 | 90 | 12 | 17.8 | 10.5 | M10 | 7° |
| BT40-M10S-110 | 110 | 12 | 15.4 | 10.5 | M10 | 7° |
| BT40-M10-110 | 110 | 12 | 17.8 | 10.5 | M10 | 7° |
| BT40-M10S-135 | 135 | 12 | 15.4 | 10.5 | M10 | 7° |
| BT40-M10-135 | 135 | 12 | 17.8 | 10.5 | M10 | 7° |
| BT40-M12-60 | 60 | 12 | 20.8 | 12.5 | M12 | 6° |
| BT40-M12H-60 | 60 | 12 | 23 | 12.5 | M12 | 6° |
| BT40-M12-90 | 90 | 12 | 20.8 | 12.5 | M12 | 6° |
| BT40-M12H-90 | 90 | 12 | 23 | 12.5 | M12 | 6° |
| BT40-M12-110 | 110 | 12 | 20.8 | 12.5 | M12 | 6° |
| BT40-M12H-110 | 110 | 12 | 23 | 12.5 | M12 | 6° |
| BT40-M12-135 | 135 | 12 | 20.8 | 12.5 | M12 | 6° |
| BT40-M12H-135 | 135 | 12 | 23 | 12.5 | M12 | 6° |
| BT40-M16-60 | 60 | 12 | 28.8 | 17 | M16 | 6° |
| BT40-M16H-60 | 60 | 12 | 38 | 17 | M16 | 6° |
| BT40-M16-90 | 90 | 12 | 28.8 | 17 | M16 | 6° |
| BT40-M16H-90 | 90 | 12 | 38 | 17 | M16 | 3° |
| BT40-M16-110 | 110 | 12 | 28.8 | 17 | M16 | 6° |
| BT40-M16-135 |
