Low Tensile Carbon Steel Seamless Boiler Tubes BS3059-1 Grade 320 OD 12 - 127mm

BS3059-1 STEEL BOILER AND SUPERHEATER TUBES

Part 1: Specification for low tensile carbon steel tubes without specified elevated temperature properties

Specifications:

Surface Treatment: Oiling/Black painting/Varnish/Passivation/Phosphating/Pickling

Ends: PE, ends caps

Marking: as per requirement

Delivery Condition: Annealed/Normalized/Tempered

Size:(mm)
? ? ? OD: 12 – 127mm ?????????WT: 1 – 12.5mm

?? or as per customer’s requirement
Length: ≤16m. Fixed Length (6m,9m,12m, 16m or as per requirement) or random length

Package: Hexagonal Bundles with steel strips and plastic wrapping outside/Wooden box/Wooden crate/Steel frame/As per customer’s requirement

CHEMICAL COMPOSITION (%):

MECHNICAL PROPERTIES:

INSPECTION AND TEST:

CHEMICAL COMPOSTION TEST. MECHANICAL PROPERTIES TEST(tensile strength, yield strength, elongation, flaring, flattening,impact, etc). SURFACE AND DIMENSION CHECK. NON-DESTRUCTIVE TEST(eddy current test/ultrasonic test), HYDRAULIC TEST.

Description:

This part of BS3059 specifies requirements for plain end, seamless and welded, low tensile carbon steel tubes, not exceeding 127mm outside diameter and not exceeding 12.5 mm thickness for use in boilers and superheaters. Only one grade of steel is included in the specification and is designated 320.

Top quality products

Applications:

Boiler tube and superheater service. Boiler flue, air preheating pipe line, superheater. Heat-exchanger and other heat supply/heat transfer equipment, etc.?

Competitive Advantage:

Always put quality on first consideration makes us keep our qulity stable and good. Always put customer’s benefit before ours makes our good service and gain us good reputation.

Advanced equipments. Sincere , truth and careful attitude on communication and production.
