Home > Products > Angular Contact Ball Bearing > 3305-BD-TVH Angular Contact Ball Bearings 30 C - +150 C Open Temperature
3305-BD-TVH Angular Contact Ball Bearings 30 C - +150 C Open Temperature
US$ 4 - 5
/ Piece
1 Piece(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Steel Double Row Angular Contact Ball Bearing 34BWD11 34x64x37mm
-
P6 P5 P4 Double Row Ball Bearing , Industrial Ball Bearings 3304-BD-TVH
-
3303-BD-TVH High Speed Angular Contact Ball Bearing 17 X 47 X 22.2 mm
-
Professional Double Row Angular Contact Ball Bearing Low Friction 3302-BD-TVH
-
3804-B-TVH Precision Angular Contact Bearings , High Speed Ball Bearing
-
Custom Double Row Angular Contact Ball Bearing High Precision 3803-B-TVH
Product Details
| Brand Name | NFCase | Place of Origin | China | |
| Model Number | AIA-1 |
Product Description
Certification:CE,FCC,MSDS
3305-BD-TVH Angular Contact Ball Bearings –30 °C - +150 °C Open Temperature
| BearingModel | 3305-BD ? 3305-BD-TVH |
| Contact Angle | 30° |
| Type | Double Row Angular Contact?Ball Bearing |
| d?(mm)? | 25 |
| D (mm) | 62 |
| B?(mm) | 25.4 |
| Mass?(KG) | 0.36 |
| Precision |
P6, P5 ,P4 ,P2 |
We currently have 660.pcs of?3305-BD 3305-BD-TVH?Angular Contact Bearing?
In Stock.If you are interested,just?feel free to contact us by E-mail or Phone.
We\'ll?assure you the best quality; the most competitive prices &?the shortest delivery time.
We also have?Items given as below In Stock.For more details,just feel free to contact us.
|
Bearing Model |
d (mm) |
D (mm) |
B (mm) |
| 3302-BD-TVH | 15 | 42 | 19 |
| 3303-BD-TVH | 17 | 47 | 22,2 |
| 3304-BD | 20 | 52 | 22,2 |
| 3304-BD-TVH | 20 | 52 | 22,2 |
| 3305-BD | 25 | 62 | 25,4 |
| 3305-BD-TVH | 25 | 62 | 25,4 |
| 3306-BD | 30 | 72 | 30,2 |
| 3306-BD-TVH | 30 | 72 | 30,2 |
| 3307-BD | 35 | 80 | 34,9 |
| 3307-BD-TVH | 35 | 80 | 34,9 |
| 3308-BD | 40 | 90 | 36,5 |
| 3308-BD-TVH | 40 | 90 | 36,5 |
| 3309-BD | 45 | 100 | 39,7 |
| 3309-BD-TVH | 45 | 100 | 39,7 |
| 3310-BD | 50 | 110 | 44,4 |
| 3310-BD-TVH | 50 | 110 | 44,4 |
| 3311-BD | 55 | 120 | 49,2 |
| 3311-BD-TVH | 55 | 120 | 49,2 |
|
Bearing Model |
d (mm) |
D (mm) |
B (mm) |
| 3800-B-TVH | 10 | 19 | 7 |
| 3801-B-TVH | 12 | 21 | 7 |
| 3802-B-TVH | 15 | 24 | 7 |
| 3803-B-TVH | 17 | 26 | 7 |
| 3804-B-TVH | 20 | 32 | 10 |
| 3805-B-TVH | 25 | 37 | 10 |
| 3806-B-TVH | 30 | 42 | 10 |
| 3807-B-TVH | 35 | 47 | 10 |
| 3808-B-TVH | 40 | 52 | 10 |
| 3809-B-TVH | 45 | 58 | 10 |
| 3810-B-TVH | 50 | 65 | 12 |
| 3811-B-TVH | 55 | 72 | 13 |
| 3812-B-TVH | 60 | 78 | 14 |
| 3814-B-TVH | 70 | 90 | 15 |
| 3816-B-TVH | 80 | 100 | 15 |
| Suffix | Description |
| BD | Modified?internal?construction,?contact?angle?30,?without?filling?slot |
| TVH | Solid?polyamide?snap?cage,?ball-guided |
| 2HRS | Lip?seals?on?both?sides |
| 2Z | Gap?seals?on?both?sides |
| C2 | Axial?internal?clearance?C2 |
| C3 | Axial?internal?clearance?C3 |
| C4 | Axial?internal?clearance?C4 |
| RROC | Corrotect?coating |
| S0 | Dimensional?stabilisation |
| S1 | Dimensional?stabilisation |
Introduction
Double row angular contact ball bearings are units with solid inner and outer rings and ball and cage assemblies with polyamide or sheet steel cages. Their construction is similar to a pair of single row angular contact ball bearings in an O arrangement but they are narrower to a certain extent.
Operating temperature
?? ? ?? ?
Open bear
