Hydraulic Amada CNC Press Brake Sheet Metal Processing Machinery High Speed
USD $4 - $5
/ Set
1 Set(Min.Order)
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Horizontal Cutting Metal Automatic Lathe Machine with 65mm Large Spindle Bore
-
Industrial Lathe Conventional Turning Machine Metal Cutting Equipment High Efficiency
-
Metal Sheet Folding Hydraulic Press Machine / Heavy Duty CNC Bending Machinery
-
CNC Plate Sheet Metal Bending Machine Hydraulic Press Brake steel welded structure
-
Hydraulic Metal Plate CNC Press Brake Machine WC67Y High Efficiency
-
Metal Plate Atuomaitic CNC Press Brake Machinery High Efficiency and High Precision
Product Details
| Brand Name | NFCase | Place of Origin | China | |
| Model Number | AIA-1 |
Product Description
Certification:CE,FCC,MSDS
Amada Technology Hydraulic Press Brake for Sale with Delem DA41 CNC Press Brake Europe ?Machinery
Products information
1. Totally European design,streamlined looking
2. Taking off inner-stress of welded parts by tempering,good stability
3. Remove rust with sand-blast and coated with anti-rust paint
4. Frames, assembly surfaces and connection holes are machined after the welding process,up to 60\' in a single pass.
Features of hengjian press brake
Main structure is of series WC67Y type , with simple-type special-purpose digital control system.
With back gauge digital , x-axis soft restrict position ,and hinting function of unit postion clearance.
Backgauge has encoder that coordinate with digital control dispaly system, in order to make disply of the backgauge more accurate, and therefore further improve the precision of this machine.
Main specification
| Type | Nominal Force(mm) | Worktable length(mm) |
Poles distance (mm) |
Throat depth (mm) |
Slider traver (mm)? |
Max open (mm) |
Power (kw) |
Dimention L*W*H(mm) |
| 40t/2200 | 400 | 2200 | 1850 | 230 | 100 | 320 | 5.5 | 2200*1200*1910 |
| 40t/2500 | 400 | 2500 | 2030 | 230 | 100 | 320 | 5.5 | 2500*1200*1910 |
| 50t/2500 | 400 | 2500 | 1970 | 230 | 100 | 320 | 5.5 | 2500*1200*2000 |
| 63t/2500 | 500 | 2500 | 1970 | 250 | 100 | 320 | 5.5 | 2500*1300*2210 |
| 63t/3200 | 630 | 3200 | 2500 | 250 | 100 | 320 | 5.5 | 3200*1300*2210 |
| 80t/2500 | 630 | 2500 | 1970 | 250 | 100 | 340 | 7.5 | 2500*1450*2300 |
| 80t/3200 | 800 | 3200 | 2500 | 250 | 100 | 340 | 7.5 | 3200*1450*2300 |
| 80t/4000 | 800 | 4000 | 3100 | 250 | 100 | 340 | 7.5 | 4000*1450*2400 |
| 100t/2500 | 800 | 2500 | 2000 | 320 | 120 | 370 | 7.5 | 2500*1550*2500 |
| 100t/3200 | 1000 | 3200 | 2600 | 320 | 120 | 370 | 7.5 | 3200*1550*2500 |
| 100t/4000 | 1000 | 4000 | 3100 | 320 | 120 | 370 | 7.5 | 4000*1550*2500 |
| 125t/3200 | 1000 | 3200 | 2600 | 320 | 120 | 370 | 7.5 | 3200*1550*2500 |
| 125t/4000 | 1250 | 4000 | 3100 | 320 | 120 | 370 | 7.5 | 4000*1550*2500 |
| 160t/3200 | 1600 | 3200 | 2510 | 320 | 200 | 450 | 11 | 3200*1700*2800 |
| 160t/4000 | 1600 | 4000 | 3040 | 320 | 200 | 450 | 11 | 4000*1700*2800 |
| 160t/5000 | 1600 | 5000 | 3800 | 320 | 200 | 450 | 11 | 5000*1900*3100 |
| 160t/6000 | 1600 | 6000 | 4600 | 320 | 200 | 450 | 11 | 6300*1900*3100 |
| 200t/3200 | 2000 | 3200 | 2510 | 320 | 200 | 450 | 15 | 3200*1900*2800 |
| 200t/4000 | 2000 | 4000 | 3040 | 320 | 200 | 450 | 15 | 4000*1950*2800 |
| 200t/5000 | 2000 | 5000 | 3800 | 320 | 200 | 450 | 15 | 5000*1950*3000 |
| 200t/6000 | 2000 | 6000 | 5000 | 320 | 200 | 450 | 15 | 8000*1950*3300 |
