Vertical Single Door Optical Coating Machine For Anti Fog Snow Eyewear

FOB Price

US$ 4 - 5 / Set

1 Set(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	NFCase		Place of Origin	China
Model Number	AIA-1

Product Description

Delivery Time:3-5 days
Certification:CE,FCC,MSDS

Optical coating machine for Anti fog snow eyewear with REVO coating glasses

Features:

Capable of equipping Ion Source or plasma gun for depositing multi-layer and precise optical coatings.

When equipped substrate reverses mechanism, it would greatly reduce the processing time, get higher throughput, and lower production cost per unit.

With its hi-performance layer monitoring system and computerized system, it can fulfill precise thickness requirement for optical layer coating

Process control system runs on Windows system interface and easy to use

Repeatable and reliable coating

Applications:

APS/ DSC / DSLR Camera Lens

PTV/ Liquid Crystal Projector Lens

Dichroic filter/ mirror

IR/ UV cut filter

DVD pick-up head and CCTV Lens

AR coating

Tag Keywords

crucible electronic gun / ebeam evaporation machine / deposition system?, vacuum coater , ebeam , E-beam .

Optical coating machine , Anti fog snow eyewear , REVO coating glasses

?Professional

we have over 15 years experience in coating machine industry,and invited the main engineer from Italy.The high-speed mayer bar coating machine is the most advanced BOPP coating machine in China.We can provide you the?best production scheme?according to your material.

Creditable

We producing?strictly according?to the contract. Every part we use for the machine must?meet the requirement?from the buyer.

Responsible

To reslove buyers\' worries is our?first task.We always treat buyers\'profit as our?first priority.We commit to produce the most?energy-saving and most efficent?machines to ensure our customer have?an edge over?their competitors.

Parameters :?

model	OEC630	OEC900	OEC1100	OEC1200	OEC1350	OEC1600
application	Plating system for multilayer film, antireflection film, filters and beam splitting film, 7 colour film, cold light film, reflective film, etc.
Principal dimension	Inside the chamber	φ630×800	φ900×1100	φ1100×1300	φ1200×1450	φ1350×1500	φ1600×1500
Substrate umbrella stand	φ570	φ820	Φ1000	φ1100	φ1250	φ1500
Umbrella stand rotary speed	0~30r/min,continuously adjustable
Major parameter	Vacuumizing speed	From one bar to 5.0×10-3Pa＜12 minutes(no-load)
Ultimate vacuum	＜3.0×10-4Pa
Substrate temperature	350°C(maximum)
Exhaust system	Exhaust vacuum pumps	KT400 oil diffusion pump system	KT600 oil diffusion pump system	KT800 oil diffusion pump system	KT600 oil diffusion pump system	KT800 oil diffusion pump system	KT800 oil diffusion pump system
Cryogenic trap	Selective assembly
Heating system	Heating method	Up heating mode,heating plate adjust the heating power regional ,PID control
Heating power	6KW	6KW	12KW	12KW	24KW	48KW
Crystalline diaphragm thickness gauge	SQC-310(or XTC-3)
Vacuum gauge	thermocouple+thermionic cathode (Domestic)
flowmeter	Yamatak
