Indoor IP67 / IP65 P4 SMD0807 Dot Matrix Virtual Led TV Display Signs

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HJY		Place of Origin	China
Model Number	P4

Product Description

Indoor IP67 /? IP65 P4 SMD0807 dot matrix virtual led TV display signs Specifications Indoor high definition P4 led TV display signs
High definition
Great performance
Supply free-training course
Long life span

Indoor high definition P4 led TV display signs

1.Products function introduction:

?1) High intensity and can be adjusted, so can meet the request of the customers according the application environment.

2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light

3) To pictures and character, have clear, exquisite and real display effect

4) Big viewing angle to 110 degree at horizontal line, 60 degree at vertical line, you can see at every angle at this range, no picture change, no color excursion

5) Can repair each led lamps, so the cost of maintain is lower, and easy to repair.

6)waterproof; IP68,67,65

2.Specifications:

classification	P4
Real or virtual	Full color real
Pixel pitch	4mm
Size of module	128*128mm
Pixel density	62500 dots/m2
Pixel composition	1R1G1B
LED encapsulation	SMD0807
Resolution of module	32*32
Power consumption of module	35W
Best viewing distance	4m
Best viewing angle(H)	140°/120°
Max power consumption	2000W/m2
Size of standard cabinet	512*384mm
Resolution of standard cabinet	128*96
Weight of standard cabinet	15kg( waterproof)
Driving IC( 5026 optional)	MBI5024GP
Driving method	1/8 constant
Frame frequency	≥60Hz/s
Refresh rate	≥360Hz/s
White balance brightness	≥2500cd/m2
Working environment temperature	-20°C-50°C lower temperature is optional
Working voltage	220±10% or 110 ± 10%
Grey scale	Display colors ≥16.7M(synchronized)
Brightness adjustment	256 levels of each color can be Adjusted manually, and 8 levels of each color can be adjusted automatically
Signal input	RF, S-Video, etc.
Control system	PCTV nonlinear editing card + DVI display card+ main controller card + optic fiber transmission? optional.
