High Precision Centerless Grinding Machine

1. Salient features:
1.1 For Grinding wheel and Regulating wheel

1.1.1.Thediameter of grinding wheel is 600mm, with strong grinding force.

1.1.2.Thewide grinding wheel can increase the grinding allowance in a single pass, anddecrease repeating, to raise efficiency.

1.1.3.Thegrinder designed for fixed grinding wheel and movable regulating wheel.

1.1.4.Thespindles of grinding wheel adopted cantilevered type & muti-plate ballsupport dynamic oil film bearing.

1.1.5.Thespindles of regulating wheel adopted double row cylindrical roller bearing,with double supported wheel.

1.1.6.Lubricationof grinding wheel spindle with thermostat.

1.2.Electric

1.2.1.ACfrequency converter is used for regulating wheel stepless speed control, aswell as reverse towing prevent function.

1.3. Dressing

1.3.1.Servo motor drives the ball screw & double “V” roller guideway are adoptedon grinding wheel dresser, steps adjustable.

1.3.2.Gear motor driven the ball screw & double “V” roller guideway are adoptedon regulating wheel, step-less speed.

1.4.Cooling

1.4.1.Thecoolant system is equipped with magnetic coolant separator.

1.5.Control system

1.5.1.10.4”touch panel, automatic plunge-cut grinding, the load, speed, time and steplevel adjustable.

1.5.2.PLC or CNC system optional.

1.6. Machine body and design

1.6.1.The modularization design has good looking. Its configuration can be selectedas client needs.

1.6.2.Iron casting with high rigidity, natural aging.

Main Application:

Thegrinder is mainly used for through-feed grinding of cylindrical surface andring-type parts, as well as for plunge-cut grinding of various stepped, conesthat the conicity less than 1:20 .
