High Strength Tempered Fire Resistant Glass / Fireproof Glass 19mm For Curtain Wall/120s

Quick Detail:

1. Thickness: 5mm, 6mm, 8mm, 10mm, 12mm, 15mm and 19mm

2. Max. size: 2400×4500mm, Min. size: 200mm × 250mm

3. Colors: Clear, F green, light green, ocean blue, Ford blue, Euro Grey, light Grey, dark Grey, bronze, gold, green blue

4. Applications:Entrance doors/ windows; Curtain walls for residential and commercial buildings; Curtain walls for fire-resistant function; safe exits

High Strength Tempered Fire Resistant Glass / Fireproof Glass 19mm For Curtain Wall/120S

Description:

Fire-resistant glass is the special glass that can keep integrality and heat insulation under the condition of fire-enduring experimentation

Fire resistance glass/fireproof glass/fire rated glass adopt special process to promote the heat stability performance of float glass and could classify different grades in 45min to 90min range according the time against to fire and heat attack. Then this could stop the spread of fire and leave enough time to escape and put out the fire. The two surfaces of the monolithic fire glass have the same performance against to fire. Fire resistant glass/ fireproof glass/fire rated glass could promote the strength performance, wind resistance performance and safety performance if you use fire resistance glass in curtain wall of architecture. Fire resistant glass/ fireproof glass/fire rated glass has excellent performance to bear high strength and to resist fire, and is extensively used in modern curtain walls, doors and windows to fulfill its outstanding safety advantage.
?

Applications:

Entrance doors/ windows; Curtain walls for residential and commercial buildings; Curtain walls for fire-resistant function; safe exits

Specifications:

Like tempered glass, after glass size is confirmed, fire resistant glass/fire proof glass/fire rated glass can not be made mechanical treatment, otherwise, fire resistant glass/fire proof glass/fire rated glass will be broken.

Competitive Advantage:

Performance of fire resistant glass/ fireproof glass/fire rated glass
In the flame environment of over 1000 degrees, fire resistant glass/ fireproof glass/fire rated glass can remain unblasted for 80 to 120 minutes, which strength ability is 6 to 12 times of the float glass, 1.5-3 times of the tempered glass.
Safety performance: Fire resistant glass/fire proof glass/fire rated glass will appear hurtless obtuse angles when breakage.
Strength performance: Six times more than float glass and have better performance comparing to tempered glass.
Heat stability performance: Have better performance comparing to tempered glass.

The single leaf fire resist glass is outstanding in its weather-suitability and high strength so it massively increases the safety in glass curtain wall.
1. When fire breaks out inside door:
The monolithic high strength and cesium-kalium fire resistant glass can bear high temperature of about 1000 degrees for 1. 5 hours and would not explode.
2. When fire breaks out outside door
The monolithic high strength and cesium-kalium fire resistant glass can effectively stops the fire from spreading and thus protect livings and properties inside the door.
3. The monolithic high strength and cesium-kalium fire resistant glass can be processed to laminated glass, insulated glass, edging, drilling.

Tag:

fire-resisting glass,flame resistant glass,flame-proof glass,Fireproof glass
