Solar Powered Auto-darkening Welding Helmet DIN 4 / DIN 913 9944 mm

Solar Powered Auto-darkening Welding Helmet ,? DIN 4 / DIN 9－13 99×44 mm

This patent product will provide eye protection against Ultraviolet and Infrared emissions, is suitable for all arc welding machine, as well as TIG, MIG, MAG, Co2, especially for Inverter welding machine. You can adjust the shade by the knob of “Shade” according to welding current, and adjust sensitivity step less. The solar cell can supply energy from welding light or natural light, and there are 2 AAA batteries can be replaced to longer the life of the filter. The high light of this patent product is: we put a LED light in the ADF (auto-darkening filter), when work in dark condition (less then 50 LUX), the LED will turn on automatically, focused by a magnify lens, we will get much bright light in 6 to 8 cm circle, help you to see clearly, it surely will be a good helper for your welding work. This mask was painted with silver background and watermark with fire pattern.

Technical Specification

·Cartridge Size:?????????? ?110×90×13 mm

·Viewing Window:???????? ???99×44 mm

·Switch Time:(light to dark)?? ????0.1ms

·Delay Time: (dark to light)?? ?0.2- 0.7 S(Automatically)

·Ultraviolet Protection:??? < 0.0003%(313 nm),

< 0.006% (365 nm)

·Infrared Protection:????? < 0.01%(780- 2000nm)

·Shade Range:???? ?????????DIN 4 / 9－13

·Sensitivity:??????????? Adjustable step less

·LED Light:??????? ??????18,000 LUX

·Battery: ????????????Solar Cell + 2 AAA

·Material:??????????????? PP Fire Resistant

·Weight:????? ????????????520g

·Operating Temperature: - 5℃ to +55℃

Quick Details

Applications:

If you do arc welding work, you know the arc will burst very strong arc light, it contain with Ultraviolet and Infrared light, it will hurt our eyes, face and skin, we have to get a helmet to protect with our eyes and face, the Automatic welding mask is useful for our welding work. But normally such helmet have DIN 4 shade before welding, so when you work in dim condition, you could not see clearly for the welding parts. To solve this problem we put LED light in the filter, when the condition is lower then 50 LUX, the LED will turn on automatically, and through a magnify lens to focus the light within 6 to 8 cm circle, you can see clearly for the welding parts, after you welding the light will turn off. The mask is suitable for all arc welding machine, as well as TIG, MIG, MAG, Co2, especial for Inverter welding machine. I think this patent product will be your good helper for your welding work.

Specifications:

Our company set up more then 11 years, we are professional producer in Auto-darkening Welding Filter & Mask, this patent product will automatically turn on LED light when you welding in dim condition, will help you to see clearly before welding. The mask is suitable for all arc welding work, especially for inverter welding machine, and TIG, MIG, MAG, Co2. The technical data meet with CE standard: EN379 and ANSI Z87.1.

Competitive Advantage:

This is our PATENT design, we have received patent certification from Russia and South Africa, the application in Europe and USA still is verifying. We will give you the only product in the market, we have one yea warranty.
